The 7 Mistakes Jake Sees in DIY Installs—and How He Fixes Them in Under an Hour

0 comments

DIY installs are becoming more popular—especially with the rise of R-32 condensers, pre-charged line sets, and online HVAC kits. Jake loves this trend… when it’s done right.

But more often than not, he gets called for one reason:

“The system is cooling, but not great.”
“It makes a weird noise.”
“The lines are sweating.”
“My vacuum won’t go below 1,000 microns.”

Every time, Jake finds the same 7 mistakes—and luckily, they’re all easy to fix in under an hour if you know what you’re looking for.

2.5 Ton Up To 15 SEER2 Goodman Air Conditioner Model - GLXS3BN3010

This is Jake’s detailed guide to the mistakes he sees most often, why they happen, and exactly how he fixes them.

❌ 1. Mistake: Kinked or Over-Bent Line Sets

Why it happens

DIYers try to bend the copper by hand or force the line set into a tight corner. R-32 systems are especially sensitive to line set restrictions.

Jake’s diagnosis

Suction line sweating excessively
High superheat
Low efficiency
Compressor running hot

Jake’s fix (15–25 minutes)

Locate the kink
Cut out the damaged section
Re-flare or braze in a coupler
Pressure test with nitrogen
Pull vacuum again

Jake says:

“Never bend copper tighter than the size of a dinner plate.”

Verified Link

NAVAC Line Set Tools
https://navacglobal.com/

🔧 2. Mistake: Loose or Under-Torqued Flare Fittings

Why it happens

DIYers hand-tighten flares because they’re afraid of overtightening. But under-tightened flares leak—slowly.

Jake’s diagnosis

Oil residue around flare nuts
System losing charge over time
Poor cooling
High head pressure

Jake’s fix (10–15 minutes)

Remove the flare
Re-flare with a proper tool
Torque to manufacturer specs
Pressure test at 300 psi
Vacuum down

Jake’s torque rule

“Hand-tight is not tight. Only torque is tight.”

Yellow Jacket Digital Torque Wrench

💨 3. Mistake: No Nitrogen When Brazing (Oxidized Lines)

This is the #1 killer of TXVs, distributors, and compressor screens.

Why it happens

DIYers watch YouTube videos about brazing but skip the nitrogen sweep because it’s “extra work.”

Jake’s diagnosis

TXV restricted
Black flakes inside copper
Poor cooling
Compressor noise

Jake’s fix (45–60 minutes)

Cut out damaged line
Flush system
Re-braze with nitrogen flowing at 1–3 SCFH
Pressure test
Vacuum to 300 microns

Jake says:

“If you brazed without nitrogen, the line set is contaminated. Period.”

Victor Nitrogen Regulator

📦 4. Mistake: The Condenser Is Too Close to the Wall

Jake sees condensers installed:

6 inches from the wall
Inside a “corner pocket”
Under decks
Behind fences

Why it happens

DIYers assume “near the house” is good enough.

Jake’s diagnosis

Unit is loud
Compressor runs hot
Short cycling
Poor airflow

Jake’s fix (20–40 minutes)

Move condenser to proper clearance:
- 24 inches front
- 36 inches sides
- 60 inches top
- 96-inch obstruction radius
Re-anchor pad if needed
Re-straighten line set

Jake says:

“Clearance is free SEER2.”

⚡ 5. Mistake: Wrong Breaker Size or Incorrect Wire Gauge

Electrical sizing matters more than any other safety step.

Why it happens

DIYers guess the wire size or reuse whatever wire was there before.

Jake’s diagnosis

Tripping breaker
Overheated disconnect
Hard-start sound
Voltage drop

Jake’s fix (30–45 minutes)

Check MCA (Minimum Circuit Ampacity)
Check MOCP (Max Overcurrent Protection)
Run proper wire gauge (usually #10 for 30A)
Replace breaker if needed
Tighten all lugs to spec

Jake says:

“If your wires get warm, your system is losing life.”

Verified Link

Fluke 376 FC Clamp Meter
https://www.fluke.com/en-us/product/electrical-testing/clamp-meters/fluke-376-fc

🧊 6. Mistake: Poor Vacuum — Never Reaching Below 500 Microns

This is the most common DIY failure point.

Why it happens

Because DIYers try to pull a vacuum using:

cheap hoses
manifold gauges
Schrader cores still in place
low-quality pumps

Jake’s diagnosis

Microns sit at 1,500–3,000
Microns drop to 700 but rise back to 1200
Moisture boiling inside line sets

Jake’s fix (30–60 minutes)

Install core removal tools
Use vacuum-rated hoses (NOT manifold hoses)
Attach digital micron gauge directly at service port
Run pump until it hits 300 microns
Close valves & confirm it holds under 500 microns

Jake says:

“Vacuuming isn’t sucking air out. It’s boiling contaminants out.”

AccuTools BluVac Pro+ Micron Gauge
https://accutools.com/products/bluvac-pro

🌧️ 7. Mistake: Pad Not Level or Not Compacted (Unit Sinks Over Time)

Jake sees this constantly—DIYers drop the pad on soft dirt, throw the condenser on top, and call it a day.

Why it happens

They underestimate how heavy condensers are (200–300 lbs).

Jake’s diagnosis

Condenser leaning
Fan blade scraping
Oil return issues
Increased vibration

Jake’s fix (45–60 minutes)

Remove condenser
Dig footprint
Add 3–4 inches of crushed gravel
Compact with tamper
Level pad
Reinstall condenser with vibration pads

Jake says:

“If the pad sinks, the system dies young.”

Verified Link

DiversiTech Condenser Pads

🧰 Bonus: Jake’s “10-Minute Starter Checklist” for DIY Installs

Before Jake leaves any job site, he confirms:

Flare torque ✔
Vacuum under 500 microns ✔
No oil at service ports ✔
Line set insulation tight ✔
Condenser perfectly level ✔
Breaker correctly sized ✔
Proper airflow around condenser ✔

If all seven are correct, Jake knows the system will run at full performance.

🎯 Final Word from Jake

DIYers are capable of amazing installs — Jake sees it every day.

But the mistakes that ruin performance are small, simple, and easy to miss. He fixes all seven in under an hour because he knows exactly what to look for.

Jake says:
