Type
Gas Furnace
Product Line
GD9T80 Series
Fuel Type
Gas
Vent Type
Metal Exhaust
Gas Valve Configuration
Two Stage
Blower Motor
9 Speed ECM
Cabinet Configuration
Downflow/Horizontal
Gas Conversion Kit
LMP-32
Description
The Goodman GD9T80 is a reliable, energy-efficient furnace designed to keep your home warm and comfortable during the coldest months. Built with durable construction and advanced heating technology, it delivers consistent performance while helping to reduce energy costs. Its quiet operation and compact design make it an excellent choice for ensuring a cozy home environment without any disruptions. Perfect for winter, this furnace provides the dependable comfort and efficiency homeowners need to stay warm.
Unlock the full potential of your GD9T80 Furnace by checking its certified performance on the AHRI Directory and mastering Energy Guide labels with the FTC’s Consumer Guide for optimized energy efficiency and savings.
This Furnace Replaces the Following Models:
GC9C800804BX, GCEC800804BX, GDH80804BX
Warranty
Goodman offers a 10-year parts limited warranty when installed by a qualifying technician and then registered on the manufacturer's website.
Standard Features
- Two-stage gas valve provides quiet, economical heating
- Efficient and quiet multi-speed ECM circulator motor
- SureStart® Silicon Nitride igniter designed for long igniter life
- Self-diagnostic control board
- Low constant fan speed circulates air throughout the home
- Quiet, two-speed induced draft blower
- California Low NOx emissions-compliant models available
- Can not be installed in California’s South Coast AirQuality Management District (SCAQMD) and San Joaquin Valley Air Pollution Control District (SJVAPCD).
- AHRI Certified; ETL Listed
Cabinet Features
- Fully insulated, heavy-gauge steel cabinet with durable baked-enamel finish
- GD9T80: downflow, horizontal left or right
- Removable bottom for side- or bottom-return applications
- Convenient left or right connection for gas/electric service
- Cabinet air leakage ≤ 2%
- Coil and furnace fit flush for most installations
Specifications
General Information
Performance
AFUE
80%
Heating Capacity (BTU/h)
80,000
High Fire Input (BTU/h)
80,000
High Fire Output (BTU/h)
64,000
Low Fire Input (BTU/h)
56,000
Low Fire Output (BTU/h)
44,800
Maximum Air Flow (CFM)
1600 CFM
Low NOx Emissions
Yes
Electrical Details
Voltage (VAC)
115
Phase
Single Phase
Frequency (Hz)
60 Hz
Minimum Circuit Ampacity (A)
11.3
Recommended Breaker Size (A)
20
Dimensions
Cabinet Width
17.5"
Product Height
33.38"
Product Width
17.5"
Product Depth
28"
Product Weight (lbs.)
121
Shipping Weight (lbs.)
121
Certifications
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
215358014
Warranty
Parts Warranty
10-Year Parts Limited Warranty
Heat Exchanger
Lifetime Limited Warranty
