Goodman 3.5 Ton 15.2 SEER2 System: R32 Air Conditioner Condenser model GLXS4BA4210, Horizontal coil CHPTA4230C3, Modular Blower MBVB16CP1X00

GOODMAN SKU: GLXS4BA4210,CHPTA4230C3,MBVB16CP1X00

Goodman 3.5 Ton 15.2 SEER2 System: R32 Air Conditioner Condenser model GLXS4BA4210, Horizontal coil CHPTA4230C3, Modular Blower MBVB16CP1X00

  • New R32 Freon,  meets the 2025 refrigerant change guidelines.
  • Pre-charged for a 15 foot line set
  • Due to new R32 regulations addtional accessories may be required for some applications, R32 equipment is NOT compatible with R410A equipment;
  • Please check with your qualified installer to ensure you are getting everything needed for your application.
  • Shipping factory direct, please provide most accurate  contact information for your order.
Save $660.99
GOODMANSKU: GLXS4BA4210,CHPTA4230C3,MBVB16CP1X00
Ready to Ship - Average Delivery Time of 1.85 Days
Retail price:
$3,304.97 USD $3,965.96 USD

Description

AHRI Certified Match: 214859884

Goodman 3.5 Ton 15.2 SEER2 R32 Air Conditioner Condenser, Model GLXS4BA4210

Standard Features

  • High efficiency Energy-efficient compressor
  • High-density foam compressor
  • Advanced Copeland® Technology
  • Fully charged for 15' of tubing length
  • Copper tube/ enhanced aluminum fin coil-5mm diameter
  • Factory-installed filter drier
  • Sweat connection service valves with easy access to gauge ports
  • Enclosed contactor
  • High-pressure switch
  • Ground lug connection
  • Capacitors with extended life
  • AHRI Certified
  • ETL Listed

Cabinet Features

  • Removable grille-style top design compliant with UL 60335-2-40
  • Venturi for increased velocity of airflow
  • Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
  • Wire fan discharge grille
  • Steel louver coil guard
  • Top and side maintenance access
  • Single-panel access to controls with space provided for field-installed accessories
  • When properly anchored, meets the 2023 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)

Goodman 3.5 Ton Horizontal Cased Painted A Coil with built in TXV Rated for use with R32. Model, CHPTA4230C3

0

Goodman 1600 CFM Multi-Positional Modular Blower with Variable-Speed ECM Motor and ComfortBridge Compatibility, in a 21 in. wide Painted Cabinet. 208/230V, 1 Phase, 60Hz Model, MBVB16CP1X00

Product Features

  • Variable-speed ECM blower motor
  • Integrated communicating ComfortBridge™ Technology
  • Commissioning and diagnostics via on-board Bluetooth with the CoolCloud™ phone and tablet application
  • Advanced configuration of the airflow and tonnage in communicating mode
  • Provides constant CFM over a wide range of static pressure conditions independent of duct system
  • CFM indicator
  • Fault recall of six most recent faults
  • Provides adjustable low CFM for efficient fan-only operation
  • Improved humidity and comfort control
  • Built-in compatibility with multi-stage heat pump and cooling applications
  • UL 60335 2-40 Compliant
  • AHRI certified; ETL listed

Cabinet Features

  • Blower section usable as electric heater
  • Horizontal or vertical configuration capabilities
  • 21” depth for easier attic access
  • Foil-faced insulation covers the internal casing to reduce cabinet condensation
  • Galvanized, leather grain-embossed finish
  • Cabinet air leakage less than 2% at 1.0 inch H₂0 when tested in accordance with ASHRE standard 193
  • Cabinet air leakage less than 1.4% at 0.5 inch H₂0 when tested in accordance with ASHRE standard 193
  • Field Installed 3 kW – 20 kW electric heater kits available
