Jake’s real-world method for diagnosing burners, tuning flame patterns, catching micro-leaks, and guaranteeing smooth ignition on every 80% furnace he installs.
80,000 BTU 80% AFUE Upflow/Horizontal Single Stage Goodman Gas Furnace - GR9S800803BN
🧰 1. The Tool Most Homeowners Don’t Know Exists — And Most Installers Don’t Use Correctly
Icon: 🧰
There are hundreds of HVAC tools Jake doesn’t care about.
But there is ONE tool he never installs a furnace without:
👉 A torch-style flame detection kit
Most techs think it’s just a “leak detector.”
Jake laughs at that.
He uses the torch/detection kit to:
-
Verify burn pattern symmetry
-
Check ignition cleanliness
-
Detect draft disturbances
-
Confirm crossover consistency
-
Identify low-flow anomalies
-
Spot burner rust or carboning
-
Check flame stability under blower load
-
Inspect gas valve performance
-
Verify pressure changes
-
Catch hairline cracks in burners
Jake says:
“This little flame tells me more than a manometer ever will.”
This article is Jake’s entire Precision Tool Pass — the exact sequence he uses on every GR9S800803BN install and every service call.
⭐ Jake’s Precision Tool Pass (The 10-Step Sequence)
This is the exact burner inspection ritual that guarantees:
-
Zero flame lift
-
Zero ignition pop
-
Zero stale crossover
-
Perfectly even flame rows
-
Clean blue fire
-
Quiet, smooth startup
-
No rust blowback
-
No soot formation
Let’s walk through Jake’s full routine.
🔥 2. Step 1 — Pre-Ignition Safety: Clear the Burner Path
Icon: 🔥
Before Jake even pulls out the torch:
He cleans the burner vestibule to eliminate:
-
Dust
-
Insect debris
-
Pet hair
-
Carbon flakes
-
Rust flakes
-
Sheet metal filings
Anything loose inside the burner compartment affects flame characteristics.
Jake does:
-
Vacuum the burner box
-
Brush each burner throat
-
Remove and clean combustion orifices
-
Blow out crossover ports
This ensures the tool pass reveals real problems, not dust artifacts.
🔧 3. Step 2 — Check All Burner Ports Using the Torch Flame
Icon: 🔧
Jake lights the torch and sets a steady, fixed flame length.
He holds it parallel to each burner port and looks for:
✔️ Air suction consistency
Flame should pull slightly toward the burner throat.
✔️ No turbulence
Any dancing or flicker indicates:
-
Draft issues
-
Cracked burner
-
Misaligned burner cells
✔️ Port uniformity
Flame should “lean” the same way at each port.
Bad port = bad ignition.
Jake catches them before firing the furnace.
🧯 4. Step 3 — Perform a Crossover Channel Check
Icon: 🧯
This is where the torch kit shines.
Jake places the flame:
-
Exactly at the crossover entry
-
½ inch from the metal edge
-
With fresh combustion air
He checks whether the flame:
-
Pulls evenly across the crossover
-
Flickers on one side
-
Dies out in any section
-
Flares from turbulence
A good crossover means burners ignite in a smooth left-to-right (or right-to-left) wave.
Bad crossover = ignition pop, delayed boom, or flame skip.
Jake says:
“Smooth crossover is clean ignition. Rough crossover is future callbacks.”
🌀 5. Step 4 — Light the Furnace and Observe Burn Pattern Immediately
Icon: 🌀
With the torch OFF, Jake fires the furnace.
He watches the first 2–4 seconds of flame.
This is where 90% of problems show up.
Jake evaluates:
✔️ Flame color
Clean = Blue
Dirty = Orange tips
Danger = Yellow streaks
✔️ Flame stability
Should be tight and smooth.
✔️ Flame roll
Absolutely should NOT roll out of the burner box.
✔️ Flame lifting
Indicates high static pressure or too much primary air.
✔️ Flame delay
Indicates gas pressure or crossover issues.
Most techs don’t know this:
The first 3 seconds tell the whole story.
🔍 6. Step 5 — Use the Torch Flame as a Draft Analyzer at the Draft Hood
Icon: 🔍
Jake re-lights the torch and brings it to the draft hood.
He checks:
✔️ Flame draw direction
Should lean steadily into the hood.
✔️ Spillage
If flame stays vertical or pushes outward → backdrafting.
✔️ Flicker
Indicates inconsistent draft.
✔️ Pull strength
Weak pull = cold chimney or oversized vent.
He tests the draft with:
-
Blower ON
-
Blower OFF
-
Closet door closed
-
Dryer running
-
Exhaust fans on
Jake’s rule:
“If the vent fails when the homeowner takes a shower, it fails.”
💨 7. Step 6 — Perform the “Blower Disturbance Test” Using the Torch
Icon: 💨
Jake places the flame near burner openings while the blower turns on.
He watches the flame response during blower startup.
What he looks for:
✔️ Flame staying straight
Means venting & air control are correct.
❌ Flame bending
Indicates return imbalance or duct restriction.
❌ Flame distortion
May indicate cracked heat exchanger or pressure leak.
❌ Flame being pulled back
Return duct static pressure issue sucking combustion air.
Jake says:
“If the blower changes the flame, the ductwork is trying to kill your furnace.”
🛑 8. Step 7 — Check for Micro-Leaks With Torch Distortion
Icon: 🛑
This is where Jake’s technique gets advanced.
He traces the flame along:
-
Gas manifold
-
Orifice connections
-
Gas valve joints
-
Union connection
-
Flex connector
-
Drip leg threads
Instead of using bubbles, Jake first watches flame behavior.
If the flame:
-
Pulls in
-
Pushes away
-
Wavers sharply
-
Bounces unpredictably
→ There’s a micro leak or pressure disturbance.
THEN he confirms with leak detector fluid.
Jake says:
“The flame finds leaks that soap doesn’t.”
🎯 9. Step 8 — Evaluate Burn Symmetry With the Torch as a Light Source
Icon: 🎯
Jake turns OFF furnace heat and turns ON his inspection light (or torch flame reflection).
He checks burner heads for:
-
Rust
-
Pitting
-
Carbon buildup
-
Uneven metal coloration
-
Hot spot signatures
-
Deposits inside the flame slots
The torch helps illuminate imperfections that overhead light hides.
Uneven burn signs:
-
Dark streaking
-
Uneven discoloration
-
Warped ports
Jake preemptively fixes burners rather than waiting for failure.
🔧 10. Step 9 — For LP or Low-Pressure Natural Gas, Jake Uses the Torch for Pressure Dynamics
Icon: 🔧
Low pressure creates flame instability.
Jake leaves the torch ON while adjusting:
-
Gas pressure
-
Air shutter (if present)
-
Manifold readings
He watches how the flame reacts to:
-
Slow increases
-
Sudden decreases
-
Airflow disturbances
This gives him real-time, intuitive feedback.
📈 11. Step 10 — Final Pass: Ignite, Observe, Compare, Confirm
Icon: 📈
Jake runs through one final live-fire test:
✔️ Burn pattern
Perfectly aligned, straight, blue.
✔️ Crossover
Smooth, fast, clean.
✔️ Draft
Strong, consistent, no backdraft.
✔️ Disturbance
Blower doesn’t affect flame.
✔️ Leak-free joints
No flame reactions, no bubbles.
✔️ Start-up
No ignition pop or delay.
Jake signs off only when:
“The flame stands at attention.”
