Tony explains why the heat leaving your furnace isn’t the heat reaching your rooms — and what to do about it.

---

🔥 Introduction: The Heat Leaving the Furnace Is NOT the Heat You Feel at the Register

Tony likes to walk into a cold room, put his hand up to the vent, and hear a homeowner say:

“But the furnace is brand new — why does the air feel weak or barely warm?”

Tony smiles because he already knows the truth:

Your system may be producing 120°F supply air…
but your home may only be receiving 90°F.

Where did the other 30 degrees go?

Simple:
Real homes lose BTUs inside the duct system —
before the heat ever gets to you.

Tony explains this all the time:

“Your furnace can do its job. But the ducts, floors, walls, runs, and registers?
They might be stealing half your heat before it reaches the room.”

In this article, Tony breaks down exactly where and why homes lose heating energy, using real measurements, airflow basics, and duct performance science.

Goodman 68,240 BTU 20 kW Electric Furnace with 2,000 CFM Airflow

---

📦 1. The Furnace Produces the Right Heat — But the Duct System Steals It

When most furnaces run, they produce air between:

• 110°F–125°F for gas

• 105°F–120°F for electric heat

• 85°F–105°F for heat pumps (depending on outdoor temp)

Tony calls this:

“The Heat Leaving the Box.”

But the heat leaving the box is NOT the heat reaching the vent.

Typical Home Losses Measured by Tony

A 120°F supply becomes 100°F at the register — 20°F lost to ductwork and house conditions.

The Department of Energy warns about exactly this

Tony sees it every day.

---

🏚️ 2. Leaky Ducts — The #1 Reason Homes Lose BTUs

Tony says:

“If you have duct leaks, you’re heating your attic, crawlspace, or garage. Not your house.”

Most older homes lose:

20–30% of heating output to duct leakage

according to the U.S. DOE.

Leaks occur at:

• plenum seams

• boot connections

• flex duct collars

• joints that weren’t sealed

• branch take-off connections

• return air cavities

• panned joists

• mastic drying out

• disconnected ducts (more common than you think)

Tony’s Real Findings

In 8 out of 10 homes Tony inspects:

• supply ducts leak between 10%–25%

• return ducts leak between 15%–40%

This means heat is escaping into:

• attics at 40°F

• crawlspaces at 45°F

• basements at 50–60°F

• garages at 30–50°F

Instead of reaching the rooms that need it.

EPA documentation confirms duct leakage as a primary efficiency killer:
👉 https://www.epa.gov/indoor-air-quality-iaq

---

🌬️ 3. Long Duct Runs Lose Temperature — The Longer the Run, the Colder the Air

Every duct run loses BTUs over distance.

Tony uses a simple rule:

“Every 10 feet of uninsulated duct costs you 1–2°F.”

Insulated ducts still lose heat, especially when passing through:

• unconditioned attics

• cold crawlspaces

• unfinished basements

Example Tony Measurement:

• Supply air: 118°F

• After 30 ft run in vented attic at 25°F: 104°F

• 14°F lost to thermal conduction

DOE temperature loss charts show similar values:
👉 https://www.energy.gov/energysaver/home-heating-systems

So even if the furnace is working perfectly, your ducts may cool the air before it arrives.

---

🧵 4. Flexible Ducting: Tony’s “Silent Restrictor”

Tony hates sloppy flex duct.
He calls it:

“The garden hose of HVAC — easy to kink, crush, or choke.”

Flex duct problems:

✔ Sagging → restricts airflow

✔ Compression → reduces diameter

✔ Sharp bends → raise static pressure

✔ Loose insulation → increases heat loss

✔ Poorly stretched → reduces CFM by up to 50%

The longer the flex duct, the more BTUs lost to:

• friction

• surface area heat loss

• reduced velocity

Tony sees it constantly:

• 8" flex sagging like a hammock

• 6" flex crushed by attic boxes

• long runs curled like spaghetti

• 180° loops that drop airflow by 40–70%

Even a perfectly heated home can feel cold if flex ducts choke airflow or shed heat.

---

💨 5. Low CFM = Big BTU Losses — Airflow Issues Drop Delivered Temperature

Airflow isn’t just about comfort — it’s about heat delivery.

Tony explains:

“120°F air doesn’t heat the room unless enough of it gets there.
Low CFM = low heat delivery = cold house.”

If a room needs 120 CFM but gets 70, the heating capacity drops dramatically.

Air temperature may be fine — but the volume of warm air is too low.

Where low CFM comes from:

• high static pressure

• small branch ducts

• long duct runs

• dirty coils

• clogged filters

• undersized returns

• flex duct compression

• leaking return air

• blower running too low

ACCA airflow standards emphasize proper CFM before sizing a system:
👉 https://www.acca.org

If CFM drops even 20%, heat delivery can drop 30%–50%.

---

🔥 6. Electric Heat Strips Are Especially Sensitive to Airflow Loss

Tony warns homeowners:

“Electric heat NEEDS airflow.
If airflow drops, electric heat overheats.”

Electric heat produces 105–120°F air at the furnace — but if airflow is low:

• temperature spikes to 140°F

• high limit switch trips

• furnace shuts off

• room never warms

• blower overheats

• heat strips burn out

And because the heat strips cycle off, the air arriving at the register may be as low as 85–95°F, which feels lukewarm.

DOE confirms electric resistance heat relies heavily on proper airflow:
👉 https://www.energy.gov/energysaver/electric-resistance-heating

---

🧊 7. Heat Pumps Drop BTUs FAST if Ducts Are Restrictive

Heat pumps don’t produce 120°F air.
They produce:

• 85–100°F in moderate weather

• 75–90°F in cold weather

That means any loss in ducts is amplified.

Example:

• Heat pump supply: 92°F

• After duct losses: 82°F

• Room temperature: barely rising

Tony says:

“Heat pumps don’t have heat to waste.
They need every degree they make.”

Performance is heavily airflow-dependent.
DOE heat pump documents emphasize this:
👉 https://www.energy.gov/energysaver/heat-pump-systems

Heat pumps running through poor duct systems almost always struggle.

---

🧽 8. Dirty Coils, Blower Wheels & Filters Drop BTUs Before They Leave the Furnace

Even if your ductwork is perfect, your system can lose BTUs inside the air handler.

Tony checks three components first:

1️⃣ Filter restriction

Clogged filters increase static pressure and reduce airflow.

2️⃣ Blower wheel dust

Even a thin dust layer drops airflow 10–20%.

3️⃣ Dirty evaporator coil

A dusty or clogged coil can reduce heating output 30–50%.

EPA notes indoor air quality and equipment condition directly affect airflow:
👉 https://www.epa.gov/indoor-air-quality-iaq

---

🪟 9. Register Restrictions — The Final Choke Point

Once the heated air reaches the room, it still can lose:

• speed

• volume

• temperature

because of:

✔ overly small registers

✔ furniture blocking vents

✔ floor mats covering grilles

✔ registers built into cold walls

✔ poorly installed boot connections

✔ air spilling into wall cavities

Tony often replaces:

• 2x10 floor vents

• 4x10 wall vents

with:

• 4x12

• 4x14

• high-flow grilles

• wider boots

• multi-angle faceplates

Even a better grille can restore 10–20% of heat delivery.

---

🧊 10. Cold Floors & Walls Rotating Heat Away

Some rooms steal BTUs faster than ducts can deliver them.

Tony identifies houses where heat disappears into:

• exterior walls

• uninsulated floors

• drafty crawlspaces

• vaulted ceilings

• large windows

• plaster walls with no insulation

• wall cavities connected to attic voids

These rooms feel colder because they bleed heat faster than the register can supply it.

The DOE provides insulation guidelines showing how much heat walls absorb:
👉 https://www.energy.gov/energysaver/weatherize/insulation

A perfectly functioning system might still struggle if the room loses heat too fast.

---

🔨 11. How Tony Fixes Lost BTUs — Real Solutions That Actually Work

Tony doesn’t replace equipment first.

He fixes the PATH the heat travels through.

✔ Seal duct leaks with mastic

Stops 10–30% heat loss.

✔ Add or enlarge return air

Improves CFM and restores proper temps.

✔ Replace flex duct with rigid metal

Significant airflow improvement.

✔ Raise blower speed (if safe)

Restores heating delivery.

✔ Clean coil & blower wheel

Often solves the entire problem.

✔ Add insulation around ducts

Stops heat discharge in attics/crawlspaces.

✔ Replace old registers with high-flow models

Improves room temperature by 1–3°F.

✔ Rebalance airflow

Gets more heat to problem rooms.

Tony says:

“I’ve warmed more homes with $20 worth of mastic and a new register than any new furnace could ever do.”

---

🧪 12. Real Case Study: The 120°F That Became 88°F

Tony visited a home with:

• 120°F supply temp

• Long attic duct runs

• 6" flex duct spanning 35 feet

• Small 2x10 registers

• Negative return suction

Temp at furnace:

120°F

Temp after coil:

117°F

Temp at end of duct run:

102°F

Temp at register:

88°F

The homeowner thought the furnace was bad.

Tony fixed:

• leaks

• sagging flex

• airflow quantity

• register size

• return pathway

Final register temp: 105°F

Room temp: stable and comfortable.

The furnace never needed replacing.

---

🏁 Conclusion: Your Furnace Isn’t Weak — Your Home Is Losing Heat Before You Ever Feel It

Tony says it best:

“Most homeowners don’t need a bigger furnace —
they need to stop losing the heat they already paid for.”

The heat leaving your furnace at 120°F shouldn’t become 90°F at the register.

When you fix:

• duct leaks

• long runs

• insulation gaps

• restrictive grilles

• airflow restrictions

• static pressure

• return sizing

…your home warms up faster, heats more evenly, and uses far less electricity or gas.

The furnace isn’t the problem.
The path the heat takes is.
