MEET YOUR SYSTEM: MUSCLE MEETS EFFICIENCY
You’re eyeing the Goodman 3-Ton 15.2 SEER2 system. It’s built to perform, save energy, and meet new refrigerant standards. Here's what you get:
-
GLXS4BA3610 – 3-ton condenser using R-32, a more eco-conscious refrigerant with lower global warming potential than R-410A.
-
CAPTA3626C3 – vertical cased evaporator coil, matching the tonnage for proper heat transfer.
-
GR9T961005CN – 100,000 BTU natural gas furnace with 96% AFUE, delivering serious heat with minimal waste.
You’ve got efficiency, clean comfort, and future-ready refrigerant tech on your side. But unless it’s installed properly, none of that means squat.
THE PREGAME CHECKLIST: GET THIS RIGHT BEFORE INSTALL DAY
Before you wrench a single bolt, make sure you’re prepped.
-
Do a Manual J load calc to size your system correctly. AHRI’s directory of certified products helps verify matched system performance and efficiency ratings.
-
Check code requirements and permit rules. Most cities require mechanical permits and gas line inspections. Visit your local building department or browse ICC’s mechanical code standards for a heads-up.
-
Secure EPA certification (Section 608) if you're planning to handle refrigerants. No cert = no-go. Learn what’s involved through the EPA’s official certification page.
-
Register the equipment within 60 days of install to get the full 10-year limited warranty. Skipping this step = expensive regrets. Goodman’s warranty page explains it all.
-
Buy proper tools and safety gear. Think: micron gauge, nitrogen tank, digital multimeter, torque wrenches, and PPE. HVAC installs aren’t glove-and-go projects.
INSTALL GUIDE: STEP-BY-STEP WALK-THROUGH FOR EACH COMPONENT
CONDENSER (GLXS4BA3610)
-
Set it on a level pad (not wood, not sloped, and definitely not grass).
-
Bolt it down using hurricane straps if you're in a wind-rated zone.
-
Braze in the refrigerant lines and pressure-test with nitrogen before vacuuming.
-
Pull a triple vacuum and charge it with factory-specified R-32. Follow Goodman’s subcooling specs exactly.
-
Make sure your disconnect box is securely mounted and labeled, and use conduit fittings rated for outdoor use.
EVAPORATOR COIL (CAPTA3626C3)
-
Mount it above the furnace if upflow, below if downflow.
-
Insulate the drain lines and route them with a pitch. Test the trap before you connect to the main line.
-
If you see frost buildup or get high static pressure later, this is the spot to revisit.
FURNACE (GR9T961005CN)
-
This furnace demands proper clearance—combustion air is no joke.
-
Run a flex gas line, check for leaks with a manometer, and always verify pressure drop.
-
Use a venting system rated for Category IV gas appliances—usually PVC with sealed joints.
-
Connect low-voltage wires, install a float switch, and set the dip switches for blower speed.
STARTUP TEST: CONFIRM EVERYTHING BEFORE CALLING IT DONE
You’re not finished until you test all modes:
-
Cooling mode: Check for 10°–15°F split at the supply/return vents. Verify superheat/subcool readings.
-
Heating mode: Watch for delayed ignition or burner flutter. Flame should be blue and even.
-
Airflow: Use a manometer or flow hood to confirm around 400 CFM per ton.
-
Thermostat: Program modes, check fan speeds, and test emergency heat if connected.
If anything feels off, stop and recheck. This system should fire clean and cool crisp when it’s humming.
COMMON TROUBLESHOOTING ISSUES AND HOW TO SQUASH THEM
Every system has quirks. Here’s what I see most with this bundle:
-
Outdoor unit short cycling: Could be low refrigerant, poor thermostat placement, or oversizing. Check line pressures.
-
Water leaks inside: Usually from a clogged coil drain or bad trap install. Use clear PVC for easy viewing.
-
Burner won’t light: Check flame sensor and pressure switch tubing for cracks.
-
High energy bills after install: Probably airflow issues—dirty filter, closed dampers, or undersized return.
-
R-32 pressure imbalance: A full leak test is crucial. Always follow Energy Star's install best practices.
MAINTENANCE 101: PROTECT YOUR INVESTMENT
Goodman systems are tough, but they still need TLC.
-
Clean condenser coils every spring. Hose them gently—don’t bend the fins.
-
Swap filters every 1–3 months depending on pets, dust, and allergies.
-
Inspect the furnace cabinet for signs of overheating or soot.
-
Get refrigerant levels checked annually if your system sees heavy summer use.
-
Schedule a pro tune-up yearly. You’ll keep your warranty valid and efficiency high.
Need help knowing what to look for? Browse the U.S. Department of Energy’s HVAC maintenance guide.
DIY VS. HIRING OUT: JAKE’S TAKE
You know I love a good DIY project. But this system’s not a hobby—it’s high-voltage, gas-powered machinery.
Do-it-yourself safe zones:
✅ Pouring the pad
✅ Mounting the thermostat
✅ Installing the filter
✅ Running low-voltage wire (if local code allows)
Call a pro for:
⚠️ Gas line hookups
⚠️ Refrigerant handling
⚠️ Electrical service
⚠️ Startup testing
Trying to save $1k could cost you double in damage, code violations, or invalid warranties. My advice? Tag-team the job—do the prep, call in licensed pros for the heavy stuff.
FINAL WORD: KEEP YOUR COMBO COOL, CLEAN & CONSISTENT
Keeping your Goodman GLXS4BA3610 condenser, CAPTA3626C3 coil, and GR9T961005CN furnace in top shape doesn’t require a PhD in HVAC — just some seasonal TLC and a little know-how. When you stay on top of simple tasks like filter changes, coil cleaning, and thermostat checks, you’re not just keeping your system running — you’re protecting your investment and saving money.
Still on the fence about whether this trio is the right fit for your home? Check out the Goodman 3 Ton 15.2 SEER2 System with R-32 to get the full breakdown on specs, benefits, and unbeatable value.
A little maintenance goes a long way. Do it right, and this system will have your back through every season.
Need more advanced installation tips for your GLXS4BA3610 unit? Visit: How to Keep Installation Simple with the GLXS4BA3610’s Sweat-Connection Valves.
Until next time,
- Jake, your comfort loving tech!
