Goodman AMST60DU1300 Air Handler Review: Is It Worth It?

0 comments

💪 What Is the AMST60DU1300, and Why Should You Care?

If the outdoor condenser is the heart of your HVAC system, the air handler is the lungs. It pulls in the air, pushes it over the coil, and blows it through your ducts to keep you cool—or warm if you’ve got a heat kit.

The Goodman AMST60DU1300 is a multi-position air handler built for large systems—specifically, for 4 to 5-ton setups. It’s designed to pair perfectly with R-32 refrigerant systems, like the Goodman 5 Ton 14 SEER2 R-32 System.

⚙️ Tech Specs That Matter (And What They Really Mean)

Let’s look past the tech sheet jargon and get into what actually counts:

Feature	AMST60DU1300
Cooling Capacity	Up to 60,000 BTUs
Blower Type	Multi-speed ECM
Refrigerant	Factory-charged for R-32
Cabinet	Foil-faced insulation, 22" width
Orientation	Multi-position (upflow, downflow, horizontal L/R)
Heat Strips	Up to 20 kW compatible
Warranty	10-year parts (with registration)

What does that mean for you? It means you’re getting a lot of airflow, flexible install options, and a motor smart enough to adjust speed to match your static pressure.

🔄 Multi-Speed ECM Motor: The Sweet Spot Between Cost & Comfort

The ECM (electronically commutated motor) is the real muscle in this air handler. It’s smarter than a PSC motor but doesn’t cost as much as a variable-speed setup.

Here’s why that matters:

✅ Quieter startups
✅ Smoother air delivery
✅ Better efficiency
✅ Handles higher static pressure from longer duct runs

This is especially critical in larger homes where the ducts span two stories or stretch over 50 feet. A PSC motor would struggle. But this ECM setup handles the load and keeps airflow right where it should be.

📐 Multi-Position Flexibility: A Win for Tight Installs

The AMST60DU1300 gives you upflow, downflow, horizontal left, and horizontal right configurations straight out of the box. That’s a huge advantage if:

You’re in a tight attic
You need to retrofit into an old furnace closet
Your ductwork enters from an odd angle

Jake’s seen plenty of homes where the original installer cut corners with a bad fit. This air handler reduces those headaches.

According to the U.S. Department of Energy, air handler placement and location flexibility is key to system efficiency. A poorly placed handler can cost you up to 20% more in operating costs due to duct losses.

🔧 Installation Tips (From Jake’s Own Toolkit)

Here’s the field stuff you won’t find in the brochure:

🔸 1. Check Your Drain Pan Orientation

Because this unit supports multiple configurations, you must reposition the secondary drain outlet if doing a horizontal install. Miss this, and you risk overflow during condensate backups.

🔸 2. Brace the Cabinet

At 22” wide and over 100 pounds, this thing isn’t light. If you’re mounting it above a garage or crawlspace, add vibration pads or isolation hangers to reduce rattling.

🔸 3. Set Fan Speed to Match Coil Load

Don’t just leave it on the default tap. Make sure the blower speed matches your coil tonnage and static pressure. Too low = weak airflow. Too high = noise and sweating ducts.

Jake’s golden rule: Always use a manometer and duct calculator when commissioning the system. Guessing is for rookies.

Want a deeper look? See ACCA’s Airflow Setup Guide—it covers how to measure and set blower speed correctly.

❄️ What Makes This a Perfect Match for R-32 Systems?

Not all air handlers are rated or compatible with R-32 refrigerant. But this one?

✅ Factory charged and labeled for R-32
✅ Coil built to handle higher pressures than R-410A
✅ Internal components rated A2L safe
✅ UL 60335-2-40 compliant

That means this unit won’t void your warranty—or blow a gasket—if you’re pairing it with an R-32 outdoor condenser.

Still on R-410A? Don’t bother. R-32 is cleaner, more efficient, and the new U.S. standard as per the EPA AIM Act.

🔥 Optional Heat Kit: Do You Need It?

The AMST60DU1300 supports electric heat kits up to 20 kW, which is solid for backup heat in southern zones.

Jake recommends:

10 kW for mild climates (Texas, Georgia, NC)
15–20 kW if you’re in a colder zone without gas heat

If you’ve already got a furnace handling heating duty, skip the heat kit. But for heat pump users or emergency heat setups, this kit is a lifesaver—especially during defrost cycles.

📊 Static Pressure Performance: How It Handles Big Duct Runs

The 5-ton capacity here means you’re moving about 2,000 CFM of air. That puts stress on your system—especially if your ducts were never sized right.

The AMST60DU1300 handles 0.5" to 0.8" external static pressure without choking. That’s better than most builder-grade models, which stall out above 0.4".

And yes, it matters. High ESP means:

Your coil can’t dehumidify effectively
Your blower motor runs hot
Your airflow tanks at the furthest vents

Jake’s pro tip? Before installing this air handler, have your tech do a duct leakage test and seal gaps with mastic or foil tape. You’ll get better pressure, better comfort, and lower utility bills.
