🏠 Introduction: Measuring Twice, Cutting Once

When Mike finally decided to install his Amana 11,800 BTU 115V Through-the-Wall Air Conditioner with Remote, he wasn’t nervous about the cooling power — he was nervous about the fit.

“You can buy the best unit in the world,” he said, “but if it doesn’t sit right in your wall, you’ll hear it, feel it, and regret it.”

Mike had a clear goal: he wanted his wall AC to blend in like a built-in, not stick out like a window unit. So before picking up a saw or drill, he spent a weekend planning, measuring, and sketching.

This is his complete process — from measuring and wall preparation to choosing the right sleeve and ensuring the Amana’s quiet, flush installation. If you’re wondering whether this 11,800 BTU model will fit comfortably in your wall, Mike’s story has every answer you need.

📏 1️⃣ Measuring the Space: Know Before You Cut

Before doing anything else, Mike pulled out his tape measure and blue painter’s tape. His mission: find out if his living room wall had the depth and clearance for a through-the-wall air conditioner.

📐 Amana 11,800 BTU Unit Dimensions:

Width: 24”
Height: 14.5”
Depth: 20.3”
Wall Sleeve Requirement: Standard 26” W x 15.5” H x 16.75” D

That meant the wall opening needed to accommodate a 26” x 15.5” metal wall sleeve — the universal standard for most Amana and compatible through-the-wall units.

🧰 Mike’s Measurement Checklist

He followed these five steps before confirming the location:

Locate studs using a stud finder.
Mark wall height at about 12–18 inches from the floor (ideal for even cooling).
Check wall thickness — it must be at least 5” deep to support the sleeve.
Ensure outdoor clearance (minimum 8” behind unit).
Confirm nearby outlet — the Amana runs on 115V standard household power.

“It’s not just about making it fit,” Mike explained. “It’s about making sure it has breathing room.”

📘 Reference: Energy Star – Sizing and Placement Tips

🧱 2️⃣ Understanding Wall Sleeves: The Hidden Backbone

Through-the-wall ACs aren’t just shoved into drywall — they sit inside metal sleeves that act as both a support cradle and an insulator between indoor and outdoor air.

Mike learned that Amana recommends its factory wall sleeve for optimal performance, though most universal 26” models will fit.

⚙️ Mike’s Sleeve Options

He compared two common types:

Sleeve Type	Material	Pros	Cons
Galvanized Steel (Amana Factory Sleeve)	Heavy-duty, corrosion-resistant	Long-lasting, ideal for humid climates	Slightly heavier to install
Aluminum Universal Sleeve	Lightweight, fits multiple brands	Easier DIY fit	May need weather seal tape for tight fit

He ultimately chose the Amana galvanized sleeve, citing its tighter seal and factory precision.

📘 Reference: Amana Wall Sleeve Compatibility Guide

🔨 3️⃣ Framing the Wall Opening

Because Mike’s wall wasn’t load-bearing, the framing process was straightforward — but he still reinforced the cutout to ensure the unit wouldn’t shift or rattle.

🪚 Tools He Used

Circular saw
Level
2x4 lumber for support
Construction adhesive
Silicone sealant

He framed the opening slightly larger than the sleeve dimensions (by about ¼ inch on each side) to allow for wiggle room during alignment.

“That extra quarter inch made all the difference,” Mike said. “It let me nudge the sleeve until it was perfectly level.”

📘 Guide: Home Depot – How to Cut a Wall Opening for AC

🪟 4️⃣ Positioning the Sleeve: Slope for Drainage

A crucial but often-overlooked detail: the sleeve must tilt slightly downward (¼ inch) toward the outdoors. This allows condensation to drain away from the wall.

Mike used a small wedge and level to achieve a 1°–2° downward slope. Then, he applied silicone caulk along the inner and outer perimeter to seal gaps.

He also installed foam weatherstripping between the sleeve and wall framing — this stopped vibration noise and created a snug, insulated fit.

📘 Reference: Energy.gov – Through-the-Wall AC Installation Tips

🌬️ 5️⃣ Ensuring Proper Airflow Clearance

Airflow can make or break AC performance. If the condenser (rear portion) can’t “breathe,” it overheats — especially in hot or humid climates.

Mike checked Amana’s airflow requirements:

Minimum 8” clearance behind unit outdoors
At least 2” clearance on each interior side
Unobstructed airflow from both intake and exhaust vents

He removed a decorative wall shelf and shifted a lamp a few feet away to keep air moving freely.

“Those little changes helped the unit stay quieter and cooler under load,” he said.

📘 Reference: Energy.gov – Airflow and Clearance Standards

🧰 6️⃣ Reinforcing for Stability

Even though wall units are self-supporting inside their sleeves, Mike reinforced the opening using 2x4 framing. This step made the wall more rigid, reducing vibration and noise.

He also secured the sleeve with two screws on each side — snug, but not overtightened (to avoid warping).

After tightening, he filled any remaining seams with low-expansion foam insulation to prevent air leaks.

🎨 7️⃣ Interior Design: Making It Look Built-In

Once the sleeve was in, Mike focused on aesthetic integration. He didn’t want the AC to look “added on.”

🪞 What He Did:

Installed white trim molding around the unit to match the window frames.
Used color-matched silicone to blend edges with paint.
Ran the power cord through a white plastic cable raceway (no exposed wiring).
Mounted the remote control holder next to the thermostat for easy reach.

“It looks like it’s always been there,” Mike said proudly. “People think it’s part of the original construction.”

🔇 8️⃣ Noise Control and Comfort

Wall ACs are often quieter than window units, but improper installation can amplify sound.

Mike noticed that sealing gaps around the sleeve and using foam strips under the interior frame cut noise by about 4 decibels.

📊 His Noise Readings:

Setting	Noise Level	Comparison
Low Fan	51 dB	Quiet conversation
High Fan	55 dB	Background hum
Compressor On	57 dB	Normal TV volume

That meant he could run the AC all night without being disturbed — and without the annoying rattle of loose framing.

📘 Reference: ASHRAE – Sound and Vibration Control for HVAC

🧩 9️⃣ How Big of a Room It Can Cool

Sizing is as important as fit. Mike calculated whether his 11,800 BTU Amana could comfortably handle his living area.

📏 His Room Specs

Room size: 480 sq. ft.
Ceiling height: 8 ft
Insulation: Average (1950s construction)

Using the Energy.gov sizing formula — roughly 20 BTUs per square foot — he needed about 9,600 BTUs for ideal cooling.

The Amana’s 11,800 BTU capacity gave him just the right overhead for humid summer days.

“It’s not oversized, so it doesn’t short-cycle. It runs steady and keeps things even,” Mike said.

📘 Resource: Energy.gov – Room Size and Cooling Capacity

🌡️ 10️⃣ What Happens if Your Space Is Smaller or Larger

Mike also learned that BTU oversizing and undersizing can both cause problems:

Situation	Result
Too small (e.g., <400 sq. ft.)	Unit runs nonstop, humidity stays high
Too large (e.g., >600 sq. ft.)	Cools too fast, poor humidity control
Perfect fit (450–550 sq. ft.)	Consistent temp, ideal comfort

For most bedrooms, living rooms, and medium apartments, the 11,800 BTU model is an excellent midrange choice.

📘 Reference: Consumer Reports – How to Size a Room Air Conditioner

🪚 11️⃣ Installation Lessons from Mike

After completing the installation, Mike wrote down the key lessons that made the process smoother:

✅ Do:

Measure twice, cut once.
Check wall thickness before buying a sleeve.
Use silicone on all exterior edges.
Add foam gasket tape for a snug fit.

🚫 Don’t:

Use regular window AC brackets (they’re not needed).
Forget to slope the sleeve.
Skip sealing around the edges — air leaks cost energy.

“Every mistake you avoid now saves hours of frustration later,” Mike said.

🧊 12️⃣ Ventilation & Drainage: The Unseen Details

Mike also learned that keeping the rear vents clear outdoors is critical. He avoided placing his AC near:

Overhangs that trap hot air
Bushes or tall plants
Dryer vents or exhaust fans

He kept at least 12 inches clearance above and 8 inches behind the unit — allowing air to circulate freely.

To prevent moisture problems, he checked that the sleeve’s rear drain pan sloped slightly outward.

🌬️ 13️⃣ Air Circulation Inside the Room

Mike noticed that placing the AC on one wall cooled the far corners slower. His fix? A small, quiet oscillating fan near the opposite wall to keep airflow balanced.

He later upgraded to an Amana remote thermostat for more precise temperature regulation — a feature he didn’t realize made such a big difference.

🧱 14️⃣ How Deep Is Too Deep?

Mike’s wall was 7.25” thick, which was perfect for the standard 26” sleeve.

However, if your wall exceeds 9 inches, you may need an extended sleeve or a rear grille adapter to ensure the condenser can still vent properly.

🪶 15️⃣ The Finished Look: Clean, Quiet, and Centered

After two weekends of careful measuring, framing, sealing, and decorating, Mike’s Amana looked like it belonged there all along.

He even added a small wooden ledge below the unit, turning it into a subtle design feature.

“People ask if it’s part of my home’s original design,” Mike said. “That’s exactly what I wanted.”

⚡ 16️⃣ Energy Efficiency After Installation

A well-fitted AC doesn’t just look good — it saves money.

After sealing and insulating his sleeve, Mike tracked his power use. Compared to his old window unit, the new wall installation reduced his cooling costs by 18%.

That’s because there were no air leaks, no outdoor infiltration, and steady compressor cycles thanks to proper fitment.

🧠 17️⃣ Common Fit & Design Mistakes to Avoid

Cutting into load-bearing walls.
Always check with a structural engineer or contractor first.
Ignoring insulation gaps.
Even small leaks cause drafts and noise.
Skipping slope setup.
Leads to condensation pooling or wall damage.
Mounting too high.
Hot air rises — mid-level placement ensures balanced comfort.
Blocking airflow outdoors.
Keep rear clearance open year-round

🧾 18️⃣ Technical Recap: Space & Fit Summary

Component	Minimum Requirement	Ideal Setup	Notes
Wall thickness	5”	6–8”	Reinforce if thinner
Sleeve size	26” W x 15.5” H	Standard Amana sleeve	Universal compatible
Clearance (rear)	8” min	12” optimal	For airflow and drainage
Clearance (sides)	2” min	4” ideal	Prevents noise reflection
Sleeve slope	¼” downward	1°–2°	For proper drainage

💬 19️⃣ Mike’s Final Thoughts

“This unit isn’t just about cooling — it’s about confidence. Once you measure and plan right, it becomes part of your home, not just a plug-in appliance.”

He recommends the 11,800 BTU Amana for anyone wanting reliable, built-in comfort without bulky equipment or constant noise.
