Installation Guide: What to Know Before You Cut a Hole in the Wall

1. Tony’s Rule #1: “Measure twice, cut once — because drywall doesn’t grow back.”

Installing a through-the-wall air conditioner isn’t just another Saturday project.
It’s part precision carpentry, part HVAC science, and all about getting it right the first time.

You’re not just sliding a box into a hole — you’re cutting into your home’s insulation, structure, and weather barrier.

Do it right, and you’ll have clean, quiet comfort for 15 years.
Do it wrong, and you’ll be patching leaks, fixing rot, and regretting every shortcut.

Tony’s line:

“The saw doesn’t lie. Once you cut, you own it — so know exactly what you’re doing before drywall dust flies.”

(Energy Star — Room AC Installation Guide )

2. Understand What a Through-the-Wall AC Really Is

Before you start cutting, let’s make sure you’ve got the right kind of unit.
A through-the-wall air conditioner is designed for permanent installation — unlike window units that hang in a sash or portable ones with hoses.

Key Differences

Feature	Through-the-Wall	Window Unit
Mounting	Fixed sleeve	Temporary fit
Air Seal	Tight	Loose
Efficiency	Higher (CEER 10–12)	Lower (CEER 8–9)
Longevity	10–15 years	3–6 years
Looks	Flush with the wall	Sticks out the window

Tony’s advice:

“If you’re thinking ‘I’ll just use a window unit instead’ — stop. A real wall AC is built to last, not to wiggle.”

3. Step One: Pick the Perfect Spot

This is where 90% of DIY installs go wrong. The wall you pick determines your airflow, drain path, and future maintenance.

What to Look For

✅ Exterior wall with no electrical or plumbing lines
✅ Near an outlet (dedicated 115V or 230V circuit, depending on model)
✅ Above ground level, not below grade
✅ Free of direct sun (north or east wall preferred)
✅ No obstruction outside for 2–3 feet

Avoid walls near gas lines, downspouts, or tight corners.
If you’re installing in a basement or garage, make sure the sleeve clears the foundation edge.

Tony’s note:

“Pick a spot you can reach with a ladder — not one you’ll hate cleaning the next decade.”

(DOE Safe Electrical Placement Standards )

4. Step Two: Tools and Materials Checklist

You don’t need a full contractor kit, but this isn’t a butter-knife job either.

Tools

Stud finder
Tape measure
Level
Pencil/chalk line
Reciprocating saw or oscillating multi-tool
Drill and bits
Screwdriver
Caulk gun
Utility knife

Materials

Wall sleeve (steel or polymer)
Sleeve gasket or foam seal kit
Weatherproof exterior caulk
2x4 framing lumber
Insulation foam (low-expansion type)
Stainless screws and anchors
Trim kit (optional, but clean finish)

Tony’s trick:

“Lay everything out before you cut. If you stop halfway to buy caulk, your wall’s gonna know.”

5. Step Three: Measure and Mark the Cutout

Every model has its own exact sleeve dimension, usually around 26″ W × 16.75″ D × 15.5″ H.
Mark it carefully using your level and stud finder.

Tony’s Framing Rules

Cut between studs, never through them.
Leave ¼″ extra clearance all around for insulation and adjustment.
Center the opening at least 6″ above the floor and below window height.

Use masking tape to outline your cut before sawing — it prevents drywall tearing.

Tony’s line:

“You can patch drywall. You can’t patch regret.”

6. Step Four: Frame the Opening

Now that the drywall’s cut, you’re going to build a frame box to support the sleeve.

Framing Steps

Measure the sleeve depth — usually 16.75″.
Cut four 2x4s to create a rectangular frame that matches your opening.
Secure it to wall studs with screws, checking for level.
Add shims if needed for perfect alignment.

This frame transfers the AC’s weight to the structure instead of the drywall — crucial for long-term stability.

Tony’s analogy:

“You wouldn’t park a car on cardboard. Don’t hang your AC on drywall.”

7. Step Five: Prep for Electrical

Before sliding anything in, verify your power source.
Most modern wall ACs use 115V (standard) or 230V (heavy-duty) circuits.

Check your unit’s spec label. If it says:

“Voltage: 115V / 60Hz” → Standard outlet
“Voltage: 230V / 60Hz” → Needs dedicated line

Electrical Tips

Use 12-gauge wire for 230V.
Never run cords through walls.
Install GFCI outlets in basements or near moisture zones.

If you’re not 100% sure about wiring, call an electrician for that part only.
Everything else, you can handle.

(National Electrical Code – Section 210.8 )

8. Step Six: Slide in the Wall Sleeve

The sleeve is your anchor — it sets the foundation for airflow, drainage, and weather protection.

Installation Rules

Insert sleeve flush with interior drywall and sloped ¼″ downward toward exterior.
Check with the level.
Secure the sleeve to the framing using four corner screws.
Seal around edges with foam and exterior-grade caulk.

Tony’s tip:

“If your sleeve tilts backward, you just built a rain collector. Make sure it drains out, not in.”

(Energy Star Installation Best Practices )

9. Step Seven: Install the Exterior Grille

Attach the grille or back cover that came with the sleeve.
This prevents debris, insects, and rain from getting in.

Align vents horizontally or vertically based on brand specs.
Use stainless screws — never plain steel.
Apply silicone sealant around the grille perimeter.

Tony’s line:

“If your AC sucks in leaves, it’s not filtering air — it’s composting.”

10. Step Eight: Slide in the AC Unit

Now for the fun part — installation day payoff.

Remove the front cover and filter.
Carefully slide the chassis into the sleeve rails.
Stop when you hear the alignment “click.”
Secure with retaining screws (top and sides).
Replace the front panel.

Plug it in, but don’t turn it on yet — we’ll test drainage first.

11. Step Nine: Test the Drainage

Before powering up, pour a cup of water into the condensation tray.
It should drain to the outside within 30 seconds.

If it doesn’t:

Recheck sleeve tilt
Clear weep holes
Verify the rear grille isn’t blocked.

Tony’s trick:

“If water runs the wrong way, you’ll know — because you’ll be the one mopping it up.”

(EPA Moisture Management Guidelines )

12. Step Ten: Seal, Insulate, and Trim

Final touches separate DIY jobs from pro installs.

Use foam insulation around all sleeve edges.
Add a vinyl interior trim kit or paintable caulk for a seamless finish.
Run your hand around the frame — if you feel air, seal again.

Tony’s test:

“If your candle flickers, your money’s leaking.”

13. Common Mistakes Tony’s Seen (and Fixed)

Mistake	What Happens	Tony’s Fix
Cutting through a stud	The wall loses strength	Reinforce with a header frame
Sleeve not tilted	Condensation backflow	Shim bottom ¼″ outward
No foam seal	Air leaks, insects	Use a closed-cell weatherstrip
Overfilling gaps	Sleeve warps	Use low-expansion foam only
Grille misaligned	Overheating compressor	Reinstall with vent match

Tony’s advice:

“You’re not racing the clock. Take your time — mistakes here cost you comfort later.”

14. Safety and Structural Warnings

Never cut into a load-bearing wall without consulting a pro.
Avoid exterior brick or stucco unless you’ve got masonry tools and patience.
Check for wires or pipes before sawing.
Always wear eye protection and gloves.

If your home was built before 1980, be cautious of asbestos-based insulation — hire a pro for that.

15. Post-Install Maintenance Checklist

✅ Clean filter every 30 days
✅ Vacuum the sleeve interior every spring
✅ Check for leaks or cracks in sealant annually
✅ Confirm drainage after heavy rain
✅ Re-caulk every 3–5 years

Tony’s maintenance mantra:

“A 5-minute filter clean saves 5 years on your unit.”

(Energy Star Maintenance Basics )

16. How Long Should It Take?

Experience Level	Estimated Time
Pro installer	1.5–2 hours
Experienced DIYer	3–4 hours
First-timer	5–6 hours (with coffee breaks)

Take it slow, double-check every measurement, and don’t rush sealing.

17. Cost Breakdown

Item	Average Cost
Through-the-wall AC	$800–$1,200
Wall sleeve	$100–$150
Materials (foam, caulk, trim)	$60
Tools (if not owned)	$80
Total DIY Cost	≈ $1,000–$1,400

Pro installation typically adds $400–$600 — worth it if you’re cutting through brick or stucco.

18. The Energy Efficiency Angle

A properly installed wall unit with a sealed sleeve can be 25% more efficient than a window unit.
Add R-32 refrigerant, Energy Star CEER ≥ 10.7, and smart thermostat integration, and you’ve got one of the most eco-friendly cooling systems for single rooms or apartments.

Tony’s note:

“Efficiency isn’t magic — it’s good design, installed right.”

19. When to Call a Pro

DIY is great — but there are limits.
Call an HVAC pro if:

The wall is brick, stucco, or concrete.
You’re unsure about electrical wiring.
Your unit needs a custom sleeve size.
The room has moisture or mold issues.

Paying a few hundred for expert work beats fixing a water leak inside a wall.

20. Tony’s Final Word

Cutting a hole in your wall is no small thing. But when you do it right, you’re not just installing an AC — you’re upgrading your home’s comfort for the next decade.
