Wire It Right: Pro Electrical Tips for Your 5-Ton R-32 Combo System

🛠️ Tony’s Intro: Wiring Isn’t Just Black and Red — It’s What Keeps Everything Alive

Alright, let’s talk electricity.

You’d be surprised how many HVAC installs I’ve walked onto where the mechanical work was clean, the ducting was solid... and the wiring looked like it was done by a squirrel with a Red Bull. No strain reliefs, loose grounds, splices made with tape, line sets rubbing on Romex—you name it.

Look, electricity is the heartbeat of your 5-ton combo system. And these R-32 units? They’re efficient, high-tech, and unforgiving when the wiring’s not up to par. One loose neutral or misfed conductor and your customer’s looking at trips, fried boards, or worse.

So in this post, I’m laying out real-world electrical wiring tips for anyone working with a 5-ton Goodman R-32 AC and gas furnace system—like the ones you’ll find over at The Furnace Outlet’s R-32 collection. From service disconnects to control wiring, I’ll walk you through what to do—and what to absolutely avoid.

Let’s wire it right. 🧢



🧰 Before You Touch Anything: Electrical Safety Basics

This goes without saying, but we’re dealing with high-voltage equipment, so let’s set some ground rules:

• Always shut off power at the breaker panel AND local disconnect

• Use a non-contact voltage tester before touching wires

• Wear insulated gloves and have an arc-rated meter

• Know your local and NEC code requirements

• Never assume a neutral wire is “dead”

• Label everything. Always.

If you’re not confident working around electricity, Mike Holt’s resources are some of the best in the industry for electrical safety, grounding, and code education.



🔌 Line Voltage: Sizing and Wiring the AC and Furnace Separately

One common mistake on 5-ton combo systems is assuming both the condenser and furnace can be powered from the same source. Nope.

You need two dedicated circuits:

• Condenser: Usually requires a 30–40A 240V circuit

• Furnace: Needs a 15–20A 120V circuit

• Both must be properly grounded and fused

Always verify MCA and MOCP ratings on the nameplate. For example, a GLXS4BA6010 condenser might call for MCA of 27.6 and MOCP of 40A. The GR9T961205DN furnace typically draws less than 12A, but check your model specs.

And make sure your condenser disconnect is within line of sight—it's required by NEC 440.14. That box needs to be accessible, labeled, and mounted securely.



🧩 Low-Voltage Control Wiring: Get Those Wires Clean and Labeled

This is where most of the callbacks come from—24V control wiring errors.

Best practices:

• Use 18/8 thermostat wire, solid core

• Strip only what you need—no exposed copper past the terminal

• Always label both ends (I use colored wire markers and heat shrink)

• Avoid routing near high-voltage wires—interference is real

• Use cable clamps at entry points

• Leave a service loop in case a future tech needs to redo it

I like to pre-label:

• R: Power

• C: Common

• W: Heat

• Y: Cooling

• G: Fan

• W2/Y2: Second stage (if used)

• O/B: Reversing valve (for heat pumps)

Make sure every connection is tight and tested. A loose “C” wire can cause smart thermostats to reboot or die completely.



🔋 Transformer Sizing and Board Protection

Smart stats draw more power than the old mercury jobs. If you’ve got a Nest, ecobee, or Honeywell T6, they might pull 4–6 VA continuously.

The factory 40VA transformer in most Goodman units is usually fine—but if you're running long wire runs, zone panels, or add-ons, you might need to upgrade to a 75VA model.

And protect that low-voltage side:

• Add a 3A automotive fuse inline if your board doesn’t have one

• Use surge protection on line voltage inputs

• Consider a hard start kit for compressor longevity

If you want to dive deeper into transformer loading, check out HVAC School’s explanation.



🌐 Grounding and Bonding: Get It Right or Risk a Board Blowout

This is the one step most techs rush—and it bites them.

Every component—furnace, condenser, stat—needs a dedicated equipment ground. That means:

• Grounding to the panel ground bar, not the neutral

• Using ground screws or lugs, not just relying on conduit

• Bonding the neutral bar in the panel properly (main vs subpanel)

For outdoor units, always test ground continuity between disconnect and panel. Corroded terminals or unbonded service panels can cause voltage imbalances that kill control boards.

The NEC guidelines for grounding and bonding (especially Article 250) are a must-read for any serious tech.



🔍 Testing and Commissioning the Electrical Side

Before I ever fire up a new install, I go through my pre-checks:

1. Test voltage at the condenser (L1 to L2 = 240V, L1 to G = 120V)

2. Test voltage at the furnace (L to N = 120V, L to G = 120V)

3. Verify 24V control wiring continuity

4. Manually jump R to W, Y, and G to verify function

5. Confirm fan speeds with static pressure readings

6. Check for voltage drop under load (especially if running off long circuits)

Don’t forget to take photos of your wiring layout for your records. It’ll save you (or another tech) a ton of time during future service.



🧯 Surge Protection and Electrical Longevity

Power surges don’t care how clean your install looks. Lightning, grid spikes, and bad neutrals can all wipe out a $300 board in seconds.

Here’s what I recommend:

• Install a whole-home surge protector at the panel (like the Eaton CHSP or Siemens FS140)

• Add a dedicated HVAC surge protector at the condenser

• Use fused disconnects with time-delay fuses to protect compressors

• Make sure your panel ground is clean, tight, and dry

The folks over at Electrical Business have some good real-world articles on surge protection best practices.



📏 NEC Code Tips Most Techs Overlook

Here’s some stuff I see get missed all the time that can cost you on inspections:

• Label your disconnects (“A/C,” “Furnace,” etc.)

• Keep wiring at least 1.25" from framing edges or use protection plates

• Clamp cables within 12" of entry point on metal boxes

• Use anti-short bushings on MC and BX

• Staple thermostat wires every 4.5 ft if exposed

• Maintain minimum burial depth for outdoor conduits (usually 18")

And always follow your local code amendments—they can override NEC in some cities and states.



🧠 Wrapping It Up with Tony

Alright, Rick — here’s the bottom line: clean, safe, well-routed wiring is the unsung hero of a solid HVAC install. The most efficient 5-ton R-32 system in the world won’t mean squat if you’ve got voltage drop, weak grounds, or a mystery arc blowing fuses every two weeks.

Take the time to wire it right. Label everything. Use proper gauges, double-check your specs, and don’t cut corners. That’s how you get a system that runs strong for 15+ years without callbacks or crispy boards.

If you’re getting into one of these new high-efficiency R-32 combos, I highly recommend working with matched kits like the ones you’ll find at The Furnace Outlet’s R-32 AC and Gas Furnace Collection. Clear manuals, proper wire diagrams, and tech support that’s worth something—that’s half the battle right there.

Want more installation and troubleshooting tips for your 5-ton system? Visit my ultimate guide right here!

That’s it for this round. Keep your lugs tight, your wires clean, and your circuits labeled. I’ll catch you on the next job.

—Tony the Trusted Tech 🧢
