Hey, Mike Here Again.
Nothing kills the cozy vibe faster than flipping on your electric furnace and hearing the breaker click off like it’s done for the night. I get it — it’s frustrating, inconvenient, and can be downright dangerous if ignored. The good news? Most breaker trips are your system’s way of protecting itself from damage. Let’s break down the usual suspects and how you can tackle them safely and effectively.
Common Causes of Breaker Trips in Electric Furnaces
1. Overloaded Circuit or Incorrect Breaker Size ⚠️
Electric furnaces draw a hefty amount of current—often between 40 and 100 amps or more depending on the model. If your breaker isn’t sized right for the furnace, it’s going to trip prematurely. Or worse, if the breaker is too big, it won’t trip when it should, creating a fire hazard. Make sure your breaker matches the manufacturer’s recommendations exactly. This table from the National Electrical Code (NEC) is the gold standard for breaker and wire sizing.
2. Dirty or Clogged Air Filters and Restricted Airflow 🌬️
It might sound simple, but a dirty filter is one of the biggest culprits behind tripping breakers. When airflow is restricted, heating elements get too hot and draw more current than they should. That makes your breaker trip to prevent damage. Filters should be replaced every 1–3 months, depending on usage and household conditions. The EPA recommends keeping filters clean to maintain indoor air quality and system efficiency.
3. Faulty Heating Elements 🔥
Heating elements don’t last forever. When they crack or short internally, they cause electrical shorts that trip your breaker. You can use a multimeter to test for continuity and resistance — if readings are off, it’s time to replace those elements. The team at Service Champions has a great guide on troubleshooting heating elements you should check out.
4. Loose or Damaged Wiring Connections ⚡
Vibrations and temperature changes can loosen connections over time. Loose wiring causes arcing, which can trip breakers and even start fires. Inspect the wiring around your furnace, disconnect switch, and breaker panel carefully. If you spot frayed insulation, scorch marks, or loose screws, it’s a red flag. When in doubt, get an electrician involved—safety first.
5. Shorted Contactor or Relay 🔄
Contactors and relays control power flow to your heating elements. If they short or get stuck closed, they can cause the furnace to draw continuous current, which trips the breaker. Diagnosing this requires some electrical know-how and tools—testing relays with a multimeter can confirm their health.
How to Diagnose Breaker Trips: Step-by-Step 🛠️
-
Power down completely — Flip off your main breaker and verify with a voltage tester.
-
Check the air filter — Replace it if it’s dirty or clogged.
-
Inspect wiring and connections — Look for damage, loose terminals, or signs of overheating.
-
Test heating elements — Use a multimeter to check for shorts or breaks in the elements.
-
Examine the breaker itself — Sometimes breakers wear out and trip unnecessarily; replacing the breaker might be needed.
-
Call in a licensed professional if you’re unsure or problems persist.
Never work on live wiring unless you are fully trained and equipped — electricity is no joke.
When to Call the Pros 👷
Breaker trips that keep happening despite your troubleshooting efforts are a clear sign to bring in an expert. Licensed HVAC technicians and electricians have the training and equipment to track down tricky wiring issues, test circuit integrity, and safely replace faulty components.
Sites like Angi and HomeAdvisor can help you find reputable professionals in your area.
Preventing Future Breaker Trips 🔧
-
Change filters regularly to keep airflow steady
-
Schedule annual professional furnace inspections
-
Upgrade your electrical panel if you’re running multiple heavy loads
-
Avoid DIY electrical fixes unless you’re confident and qualified
-
Use manufacturer-approved breakers and parts only
Final Words from Mike
Breaker trips are frustrating but important safety features. They keep your home and furnace from overheating or catching fire. Pay attention to them, don’t ignore repeated trips, and take action early.
If you’re thinking about a new furnace or need parts, check out The Furnace Outlet’s electric furnace collection. They’ve got solid products, great prices, and support you can trust.
Need to know how to test and replace heating elements in your electric furnace? Visit my guide: A Step-by-Step DIY Guide.
Stay safe, keep that heat on, and catch you next time.
- Mike, your cool HVAC neighbor
