Hey There, It’s Mark! 🧰
So the furnace isn’t working and it’s colder than a freezer full of fish sticks. Been there. Nothing gets the stress levels rising like a house full of cold air and a furnace that’s given up on life.
But before you reach for the phone or start pricing new systems, let’s go through some DIY steps that just might solve the problem. A lot of the time, it’s something simple—and I’ve got your back with a checklist that walks you through the process like a friendly neighbor (with a multimeter 😎).
Safety First: Before You Touch Anything ⚠️
Let’s get serious for a second.
-
Turn off power at the breaker box.
-
Make sure your hands are dry.
-
Don’t mess with high-voltage connections unless you’re confident and safe.
If anything looks burned, melted, or smells like toast? Stop and call in a pro.
1. Furnace Won’t Turn On at All 📴
Let’s start with the basics. If your furnace is completely dead:
✅ Check the Thermostat
-
Set it to “Heat” and raise the temperature above room temp.
-
Replace batteries (if it uses them).
-
If you have a smart thermostat, try rebooting it.
Still nothing? Try jumping the R and W terminals with a short wire (like a paperclip). If the furnace kicks on, your thermostat is toast.
✅ Check the Breaker
Electric furnaces pull a lot of amps. Head to your breaker panel and look for a tripped breaker or blown fuse. Reset it if needed.
✅ Look at the Disconnect Switch
There’s usually a power disconnect box near the furnace. Make sure it’s not flipped off or that the fuse inside isn’t blown.
Need a visual? Family Handyman has a great tutorial that shows you what to check.
2. Furnace Turns On but There’s No Heat 🌬️❄️
This one’s a heartbreaker—you hear the fan, but the air’s cold. Here’s what to check:
✅ Dirty Filter
A clogged air filter can cause the system to overheat and shut off the heating elements. Replace it and restart the furnace.
✅ Blown Heating Element
Electric furnaces use resistive heating coils. If one burns out, you might only get cold air.
Test continuity with a multimeter. If the reading’s open (OL), it’s dead and needs replacing.
Check out this step-by-step element test guide from the Repair Clinic if you need help.
✅ Sequencer Failure
The sequencer is like the traffic cop for the heating elements—it tells them when to turn on. If it fails, your elements might stay off.
You’ll need to test voltage across the sequencer terminals. If there’s input power but no output to the coils, it’s likely shot.
3. Weak Airflow or Strange Noises 💨🔊
✅ Blower Motor Issues
-
Make sure the blower is spinning freely.
-
Listen for humming without movement (could be a bad capacitor).
-
Check the blower motor capacitor using this HVAC School testing guide.
✅ Loose Belts or Obstructions
If it’s squealing like a banshee, check the belt tension (if applicable). Also inspect for debris like insulation or dust buildup in the blower housing.
4. Furnace Cycles On and Off Constantly 🔁
This is what we call short-cycling—and it wears out components fast.
✅ Thermostat Location
If it’s near a heat source or draft, it might be tricking your furnace into thinking the room is warm or cold when it isn’t.
✅ Overheating and Auto-Shutdown
Overheating causes the high-limit switch to cut off power to the heating elements. Causes include:
-
Dirty filter
-
Blocked vents or ductwork
-
Malfunctioning blower motor
Fix the airflow first. Then try resetting the furnace. If it keeps happening, your limit switch might be too sensitive or faulty.
5. Blowing Cold Air Sometimes, Warm Other Times 🌡️
Intermittent heat? Ugh. Here's what might be happening:
✅ Loose Wiring
Vibrations can cause terminal screws to come loose over time. Make sure all connections at the sequencer, blower, and elements are tight.
✅ Faulty Relay or Control Board
If a relay is sticking or misfiring, you’ll get inconsistent results. These can be tricky to test, so if you've ruled out the other stuff, it may be time for a technician to bench-test it.
Pro Tip: Use a Multimeter Like a Detective 🔎
If you’re serious about DIY furnace repair, invest in a decent multimeter. It’ll help you:
-
Test voltage to heating elements
-
Check thermostat signals
-
Confirm continuity in fuses and wires
Don’t guess—test. It’s what separates a confident fix from a coin toss.
When to Throw in the Towel and Call a Pro ☎️
Look, I love fixing stuff too—but there’s a time when calling an HVAC tech is the smart move:
-
Burnt smell or melted wires
-
Repeated breaker trips
-
You’ve replaced parts and the problem’s still there
-
You hear a loud bang or grinding
Websites like Angi and HomeAdvisor can help you find a licensed pro nearby. Just make sure they specialize in electric systems.
Keep It Running: Mark’s Maintenance Tips 🧽🛠️
Want to avoid these headaches in the future? Here’s what I do with every system I maintain:
-
Change your air filter every 1–3 months
-
Vacuum blower housing once a year
-
Keep registers and returns clear of obstructions
-
Check the thermostat wiring every season
-
Test heating elements at the start of winter
Even a little TLC can extend the life of your furnace by 5–10 years. Trust me, your wallet will thank you later.
Final Thoughts – Stay Warm, Stay Handy 🔧🔥
Troubleshooting an electric furnace doesn’t have to feel like defusing a bomb. Most of the time, it’s a dirty filter, a tripped breaker, or a tired thermostat. With a flashlight, a little patience, and this guide, you’re more than capable of getting your heat back on.
Still stuck? The folks at The Furnace Outlet have great support and high-quality replacement units if you’re ready to upgrade.
Trying to figure out if you need a permit to install an electric furnace? Visit: A Homeowner’s Guide to HVAC Permits.
Catch you in the next one—
—Mark, your go-to tech
