How to Install, Start Up & Maintain a Gas or Propane Unit Heater Like a Pro

The Warm-Up Series: Unit Heaters 101 — Episode 2

---

The “Fresh-Out-of-the-Box” Moment

You finally bought your dream garage heater. The box says “60,000 BTU of comfort”, and you’re itching to feel that first wave of warm air.
Hold that thought—because the next few hours decide whether your heater becomes the best purchase you’ve made this year … or the reason you’ll be Googling “garage smells like gas.”

In this guide we’ll walk through safe installation, first start-up, and maintenance so your gas or propane unit heater runs quietly, efficiently, and for years to come.

---

🔒 Before You Start: Safety First

Gas and propane heaters produce combustion gases—mainly carbon dioxide and, if something goes wrong, carbon monoxide. Proper installation and venting are literally life-saving.

1. Read the manual cover-to-cover.
   Every model—whether a Goodman, Modine, or Reznor UDXC-60 Propane Garage Heater—has unique clearance and venting requirements. Skipping the manual is like flying without a checklist.

2. Shut off power and gas.
   A single live wire or open valve can ignite residual gas during installation. Always isolate both systems before work begins.

3. Plan your ventilation.
   Exhaust gases must vent directly outdoors through a dedicated flue. A shared chimney can back-draft carbon monoxide into living spaces.

4. Choose your mount location wisely.
   Keep the heater clear of vehicles, shelving, and paint or solvent storage. Combustibles need at least 18 inches of clearance from the cabinet and exhaust.

5. Check code compliance.
   Local mechanical codes specify vent materials, clearances, and even fastener types. A quick call to your building department saves re-work later.

⚠️ Safety Pro Tip: Install a carbon-monoxide detector near the garage entry door. It’s the cheapest insurance policy you’ll ever buy.

---

---

🧱 Step 1: Mount It Right

Ceiling mounting keeps floor space open and helps heat distribute evenly.

• Find structure, not drywall. Lag bolts must anchor into joists or strut channels rated for the unit’s weight.

• Maintain level. A heater that tilts forward changes flame geometry, leading to uneven combustion and premature heat-exchanger wear.

• Respect clearances. Most units need 6–18 inches from the top and 24 inches from the front for safe airflow.

🧰 Pro Insight: Use a laser level and chalk line before drilling. Once mounted crooked, adjusting a 60-pound heater overhead is no fun.

---

🔩 Step 2: Venting & Fuel Connections

Venting:

• Use Type B double-wall vent pipe for natural gas or Type L for propane.

• Keep horizontal runs short (under 75 % of vertical height if possible). Every extra elbow adds resistance and reduces draft strength.

• Seal joints with high-temp silicone or foil tape rated for flue gas temps—not generic duct tape.

Fuel Line:

• Black-iron pipe is standard for gas; copper with flare fittings for propane.

• Include a drip leg (sediment trap) just before the heater’s gas valve—it catches rust or debris that could clog the orifice.

• Pressure-test connections with a 50/50 dish-soap and water solution. Bubbles mean leaks; tighten or reseal immediately.

🧰 Pro Insight: Propane’s higher BTU density means it needs smaller volume but higher pressure. Verify the unit’s orifices and regulator are converted for LP fuel before lighting.

---

⚡ Step 3: Electrical and Thermostat Setup

• Power supply: Most residential units use 120 V, 15-A circuits. Dedicated breakers prevent nuisance trips when the blower starts.

• Wiring: Use flexible metallic conduit for vibration resistance. Secure with proper strain reliefs—loose wiring is a top failure point.

• Thermostat location: Mount about 5 ft high on an interior wall away from drafts, windows, and direct heater airflow. Incorrect placement can cause 10 °F swings in comfort.

• Grounding: Bond all metallic components. A solid ground reduces electrical noise that can confuse newer electronic ignition controls.

---

🔥 Step 4: First Start-Up & Commissioning

Now for the fun part—making heat.

1. Purge the gas line.
   Small air pockets delay ignition and trip the safety lockout. Crack the union until you smell gas, then tighten and leak-test again.

2. Restore power and open the gas valve.
   Listen for the click of the ignition relay and the whoosh of initial flame.

3. Observe the flame through the sight glass.
   A perfect flame is crisp blue with minimal yellow tips. Lazy yellow flames mean incomplete combustion—usually dirty burners or restricted air.

4. Monitor operation for 15 minutes.
   Watch for smooth cycling and steady fan operation. Light metallic popping at first is normal as metal expands.

5. Check exhaust temperature and draft.
   Hold a small tissue near the vent outlet—it should pull gently inward, confirming proper draft.

🧰 Pro Insight: A faint “burn-in” smell for the first hour is just oil residues cooking off. If the smell continues after the first run, shut it down and inspect for misaligned vent joints.

---

🧽 Step 5: Maintenance That Matters

Maintenance isn’t optional—it’s the difference between a 10-year heater and a 25-year workhorse.

Quarterly (Every 3 Months):

• Vacuum the intake grilles and fan blades. Dust buildup reduces airflow, forcing the blower motor to draw more current and shortening its life.

• Inspect vent joints. Expansion and vibration can loosen screws; reseal if needed.

Seasonal (Before Winter Use):

• Cycle the system. Turn it on before cold weather to catch ignition or blower issues early.

• Clean burner assemblies. A quick compressed-air blowout removes cobwebs and rust flakes that cause flame distortion.

• Lubricate motor bearings if the model isn’t permanently sealed.

Annual (Professional Check):

• Heat-exchanger inspection. Cracks can leak carbon monoxide. Pros use mirror scopes or combustion analyzers to verify integrity.

• Combustion-efficiency test. Target 80–83 % for standard units, 90 % for condensing models.

• Gas-pressure test. Ensures regulators deliver factory-specified 3.5 in W.C. for gas or 10 in W.C. for propane.

🧰 Pro Insight: A dusty fan can drop heater efficiency by 10 % or more. That’s the same as tossing money out the vent. A five-minute vacuum saves fuel all winter.

---

⚙️ Step 6: Common Troubles & When to Call a Pro

Even perfect installs need occasional TLC.

When in doubt, shut it off and call a licensed HVAC technician—especially for gas smell, flame irregularity, or repeated lockouts.

🧰 Pro Insight: Most heater “failures” trace back to neglect. A $150 annual tune-up beats replacing a $1,200 heat exchanger any day.

---

💡 Efficiency and Comfort Optimization

• Insulate walls and garage doors. Every R-value point you add reduces run time.

• Ceiling fans help. Reversing a slow fan pushes warm air back down from the ceiling.

• Smart thermostats. Models with learning schedules prevent over-heating empty spaces.

🧰 Pro Insight: When you warm the garage, you also protect tools, paint, and batteries. Consistent temps reduce condensation and corrosion—hidden savings most homeowners never notice.

---

🧭 Ready for Warm Air?

You mounted it square, vented it right, wired it safe, and ran the start-up like a pro.
That steady hum you hear? That’s the sound of comfort — and efficiency — done correctly.
