Furnace Error Codes Explained: Flash Patterns, Fixes, and What You Shouldn’t Ignore

🔧 Hello from Tony

If I had a buck for every time someone sent me a video of their furnace’s control board flashing like a Christmas tree, I’d be retired in the Bahamas right now sipping freon-free piña coladas 🍹

But look—I get it. Error codes look intimidating. They're flashing numbers and patterns with no explanation unless you’ve memorized your unit’s manual (spoiler: you haven’t).

So let me help you cut through the chaos. I’ll break down:

• What those flash patterns really mean

• The top 6 most common codes you’ll see

• Easy fixes you can do yourself

• When to not mess with it anymore

Grab your flashlight and your reading glasses—here we go.



🔴 What Are Furnace Error Codes, Anyway?

Modern furnaces come with a control board, kind of like the brain of the operation. When something goes wrong—bad airflow, ignition issues, pressure switch failure—it sends a signal to a tiny LED on the board.

Instead of showing a full text message (which would be too easy), it blinks in patterns. Each blink combo means something specific.

Here’s how it works:

• 1 blink = One type of issue (usually limit switch)

• 2 blinks = Pressure switch problems

• 3–6 blinks = Varies by brand, but usually ignition or flame detection

• Rapid continuous blink = Transformer issues or reversed polarity

• No light at all = No power or fried board 😬

Your job? Match the pattern to the code chart printed right on the inside of your furnace panel. That’s your Rosetta Stone, my friend.

Need a universal breakdown? This Carrier furnace troubleshooting guide covers most code meanings even if you’re running a Goodman or Lennox.



⚠️ The 6 Most Common Furnace Error Codes and What to Do About Them

Let’s talk about the usual suspects. I’ve seen these pop up on hundreds of calls—and odds are, one of them is on your board right now.



1. 3 Blinks: Pressure Switch Failure

This one’s near the top of the list every winter. A pressure switch tells the furnace that your flue gases are venting properly. If it doesn’t close in time, the system shuts down to prevent CO buildup.

Fix it:

• Check for clogs in the vent pipe—leaves, ice, dead birds (seriously)

• Blow out the rubber tubing from the pressure switch to the inducer

• Use a manometer to check pressure, if you’ve got the tools

Still stuck? HVAC School breaks down pressure switch diagnosis in great detail.



2. 4 Blinks: Open High-Limit Switch

This means the furnace is overheating, and the high-limit switch opened to shut it down before it gets dangerous.

Fix it:

• Check for a clogged filter (the #1 cause)

• Make sure all vents are open

• Look for obstructions in the blower wheel or ductwork

If it keeps tripping, your blower motor may be undersized or failing. Don’t ignore this one—persistent overheating can crack the heat exchanger.



3. 6 Blinks: Flame Rollout or Manual Reset Tripped

Now we’re in danger zone territory. A rollout switch trips when flames roll out of the burner compartment—usually from a blocked heat exchanger or flue.

Fix it:

• Don’t reset this until you check for a cracked heat exchanger

• Inspect for blocked exhaust pipes

• Make sure burners aren’t dirty or misaligned

If you reset this without fixing the issue, you’re playing with fire—literally.



4. Rapid Continuous Blinking: Polarity Reversed or 115V Issues

The board is telling you it’s getting power, but not the way it likes. Line and neutral wires might be flipped, or the ground could be missing.

Fix it:

• Shut off power at the breaker

• Double-check your wiring connections (especially on DIY installs)

• Use a plug-in polarity tester at the outlet if you’re running from a corded setup

This one’s common with new installs. It won’t fry the board instantly, but it can cause wonky ignition cycles, premature failure, and safety switch confusion.



5. Steady No Light at All: Power Failure or Bad Board

If the LED isn’t blinking, pulsing, or doing anything—it probably means your control board isn’t getting power, or it’s completely dead.

Fix it:

• Check the furnace switch (often looks like a light switch nearby)

• Verify that the breaker isn’t tripped

• Inspect for a blown fuse on the board (usually 3A or 5A blade fuse)

• Test power to the board with a multimeter—should have 120V input and 24V output

If everything checks out and you still get no LED? It’s probably board time. Home Alliance’s DIY guide can walk you through a safe replacement if you’re brave and know your wiring.



🛑 When You Should Not Try to Fix It Yourself

Alright, here’s where I tell you to slow your roll. If your furnace is:

• Blowing cold air after multiple resets

• Tripping the same switch over and over

• Smelling like burnt wiring or gas

• Or if your CO detector is chirping

Shut it down. Call a licensed HVAC pro. No online tutorial (not even mine 😏) is worth your family’s safety.

Want a shortcut to a local technician directory? Check out Angi’s licensed HVAC listings to find someone with boots on the ground near you.



📎 Tony’s Error Code Troubleshooting Checklist

Here’s what I carry when I’m chasing blinky lights:

• Multimeter (auto-ranging, with clamp amp meter)

• Mini screwdriver set (you’ll thank me later)

• Replacement blade fuses (3A, 5A)

• Polarity tester plug

• Laminated cheat sheet of code meanings per brand

And if you’re shopping for a new system, look for units that include diagnostic displays with text, not just LED flash codes.



🙌 Final Thoughts from Tony

Blinking lights don’t mean you broke something. They mean your furnace is trying to tell you what’s wrong. Kinda like your check engine light—it’s annoying, but it’s there for a reason.

So next time your furnace blinks at you like a moody teenager, don’t panic. Use the code chart. Work through the basics. If it’s safe, reset and retry. If it smells weird or makes scary noises? Shut it down and let the pros handle it.

And hey—if your furnace is doing more blinking than heating, it might be time to upgrade. The models at The Furnace Outlet are smart, safe, and priced right for regular folks like you and me.

Curious about how to wire a gas furnace safely? Visit: What Every DIYer Needs to Know Before Touching That Panel.

Keep warm, keep safe—and keep those fingers outta the burner cabinet without turning the power off. I mean it.

Catch you on the next blog,
–Tony the Trusted Tech 🔧🔥
