Common Troubleshooting Issues with 4-Ton R-32 Systems (and How to Solve Them)

Tony the Trusted Tech Here!

Let’s be honest: 4-ton systems are awesome… when they work.

But when they don’t? You’ve got a beast of a unit that’s full of high-pressure R-32, connected to long line sets, oversized coils, maybe a zoning system — and a customer who’s already Googled five DIY fixes and thinks they know what’s wrong.

I’ve been there more times than I can count.

Today, I’m walking you through the top 4-ton R-32 AC system issues I see in the field, how to diagnose them fast, and how to solve them without throwing parts at the wall.



1. High Head Pressure Shutdowns

R-32 runs at higher pressure than R-410A, and when you install it on a hot roof or with poor airflow, things can spike fast.

Symptoms:

• Outdoor unit buzzing or humming, then clicking off

• Tripping high-pressure switch

• Condenser fan sounds like it’s struggling

Causes:

• dirty condenser coil

• overcharge (especially on long line sets)

• non-condensables in the system

• airflow restrictions in or around the condenser

Fix:

• Clean the coil (properly — not just a rinse)

• Verify charge using weight and subcooling

• Pull and weigh charge if you suspect contamination

• Check airflow clearance — 24" on all sides minimum

Want to know more about pressure dynamics with A2L refrigerants like R-32? ASHRAE has a great breakdown on safe practices under different operating conditions.



2. Freeze-Ups on the Evaporator Coil

If you see ice on the big 7/8” suction line or frost creeping down the coil, shut it down. Fast.

Symptoms:

• Low airflow

• Lukewarm supply vents

• Water dripping from the air handler

Causes:

• restricted airflow (dirty filter or blower)

• low refrigerant charge

• failed TXV or sensing bulb

• oversized system short cycling

Fix:

• Change the filter, check blower RPM

• Inspect TXV for restrictions

• Use superheat to check charge status

• Let the coil thaw fully before restarting

More than once, I’ve seen freeze-ups from systems that were sized too big for the space. Want to understand sizing better? Energy Vanguard breaks it down simply for techs and homeowners alike.



3. Short Cycling

This one kills compressors fast — especially on 4-ton units that don’t have time-delay boards.

Symptoms:

• System starts and stops every 2–3 minutes

• Inconsistent room temps

• High utility bills

Causes:

• Oversized system

• Thermostat near supply vent

• Low charge or non-condensables

• Bad contactor or stuck pressure switch

Fix:

• Add a 5-minute anti-short-cycle timer

• Relocate thermostat if needed

• Recover and recharge correctly

• Check capacitor, contactor, and sensors

Short cycling also ruins humidity control — which R-32 systems already struggle with when oversized. Want a refresher? Carrier’s guide to humidity control is worth bookmarking.



4. Refrigerant Leaks

Every ounce counts with R-32, and most 4-ton systems hold 6–10 pounds. Even a small leak can throw everything off.

Symptoms:

• System runs but barely cools

• Low suction pressure, high superheat

• Iced evaporator

• Hissing sound near joints

Causes:

• bad flare connection

• rubbing copper line (especially where it exits the unit)

• corroded indoor coil

• cracked braze joint

Fix:

• Bubble test and electronic leak detection

• Pressure test with nitrogen (don’t skip this)

• Evacuate, repair, and weigh in charge

• Label the system with leak location for future reference

The EPA’s refrigerant management rules are tightening around leak detection and reporting. Make sure you’re logging it all correctly, especially if the charge exceeds 50 pounds (rare on resi, but check your paperwork).



5. Blower Motor or ECM Failures

4-ton systems push serious airflow — up to 1,600 CFM — and if your blower motor isn’t tuned right, everything downstream suffers.

Symptoms:

• Weak airflow at vents

• Noisy blower ramping up and down

• Cold evaporator but warm supply temps

Causes:

• Wrong dip switch settings

• ECM programming error

• Dirty wheel

• Bad bearings or failing capacitor

Fix:

• Verify airflow specs based on tonnage

• Check dip switches against install manual

• Clean blower wheel thoroughly

• Replace capacitor or ECM module if needed

Want a manufacturer-specific walkthrough on testing ECMs? Goodman’s tech support site has solid PDFs and diagrams for field testing. Just use your model number and grab the right one.



Bonus: R-32 and Pressure Sensor Faults

Some of these new R-32 systems don’t use traditional pressure switches — they use sensors that talk to the board.

Symptoms:

• Flashing fault codes

• Unit won’t start, but nothing’s obviously wrong

• Normal refrigerant pressures when connected

Causes:

• Bad pressure sensor

• Sensor disconnected from board

• Voltage drop or low voltage to the board

Fix:

• Reset system fully (disconnect 24v for 5 minutes)

• Verify 5v DC reference at sensor

• Replace sensor if it shows 0v or floating signal

• Confirm board voltage is steady at 24v

These sensors are delicate. Don’t wrench on them or overtighten. And when in doubt? Call tech support — or check online forums like HVAC-Talk where techs share R-32 diagnostics all day long.



Final Thoughts from Tony

Troubleshooting 4-ton R-32 systems is no joke. There’s more pressure, more refrigerant, more things to go wrong — and less room for error.

But that also means when you nail it? The system runs quieter, cooler, and smoother than anything that came before.

My advice? Know your systems inside out. Keep good records. And never be afraid to slow down, ask the right questions, and double-check your numbers.

Need a solid 4-ton R-32 unit to work with?
👉 Browse the 4-Ton R-32 AC Systems at The Furnace Outlet

These systems are built for pros — and backed by the specs and support you need to get it right the first time.

Curious about ductwork? Visit my guide: Do 4-Ton R-32 AC Units Work with Older Ductwork? Let's Break It Down.

Until next time,
Stay cool, stay sharp — and don’t forget your clamp meter.

– Tony the Trusted Tech
