Climate Zone 3C Warm Marine HVAC Checklist for Durable, Efficient Coastal Systems

Understand 3C loads before you pick hardware

Coastal 3C (mild temps, salty air, frequent marine layer) loads are dominated by latent moisture and corrosion, not extreme sensible heat. Typical outdoor summer design might only be mid-70s °F, but nighttime RH runs high and doors/windows cycle with ocean breezes. That means systems that overshoot airflow or lack reheat will overcool without dehumidifying. Prioritize equipment that modulates capacity and airflow to keep indoor RH ~45–55% year-round.

Visual design targets

Long shoulder seasons + salty mist = coils see “winter” corrosion while doing “summer” dehumidification. Spec for both realities, not just nameplate SEER2.

Corrosion resistance: materials, coatings, and fasteners

Salt fog destroys unprotected metals by pitting fins, rotting fasteners, and seizing fan hubs. Call out aluminum microchannel or epoxy-coated fin-tube coils, powder-coated or stainless cabinets, and 304/316 SS hardware. Coastal kits with epoxy fin stock, UV-stable topcoat, and sealed electricals pay off quickly. Where platforms or rails are required, specify hot-dip galvanized or SS with dielectric isolation to avoid galvanic couples.

Spec checks (shop notes)

• Coils: epoxy (E-coat) or heresite-type coatings; verify factory coverage on tube sheets and edges.

• Cabinet: ≥2,000-hr salt-spray topcoat; gasketed panels; rain management hems.

• Fasteners: SS self-drillers; avoid mixed alloys at dissimilar joints.

Mount the condenser wind-leeward of salt spray and add a rinse bib nearby. A weekly hose-down (fresh water only) is the cheapest life-extension you can buy.

Humidity control without overcooling

In 3C, you’ll often need to pull pints, not degrees. Favor inverter heat pumps or ductless mini-splits that throttle down and drop CFM in latent mode. Look for dry/dehumidify modes and controls that allow reheat (hot-gas or electric) to trim RH at neutral temps. If ducts are long or leaky, you’ll struggle to hold 50% RH to fix the air distribution before blaming the equipment.

Visual psychrometric intent (text sketch)
Outdoor 68–72°F @ 85–95%RH → Indoor 72°F @ 50%RH (reheat or low-SHR mode)

Tune SHR by setting ~325–350 CFM/ton during marine layer events; return to 375–425 CFM/ton when sensible loads rise. Add a whole-home dehumidifier only if part-load cycling still leaves RH >55%.

System types that excel in 3C (what to spec where)

• Coastal grade air-source heat pumps (R-32): High SEER2/HSFP2, excellent part-load latent control, heat well in mild winters. Start here for most whole-home designs.

• Ductless mini-split systems: Ideal for additions, ADUs, or homes without good ducts; wall, cassette, or concealed-duct options.

• Packaged units (coastal): Simple roof/ground installs for tight lots; ensure marine coatings.

• PTAC/VTAC & through-the-wall: Good for rentals/hospitality near the beach; specify anti-corrosion coils and sleeves.

Gas furnaces see less duty in 3C but dual-fuel packaged units can pencil when electric rates are high. See R-32 dual-fuel packaged.

Sizing, airflow, and high-ceiling spaces

Short cycling ruins latent control. Use Manual J (mild design temps, meaningful infiltration) and Manual S/D to match blower tables to duct reality. In vaulted or open-plan rooms, heat stratifies while moisture collects low. Consider zoning or multi-head ductless to keep bedrooms tight overnight and living zones flexible.

Airflow tactics

• Start at 350 CFM/ton in shoulder seasons; drop for latent, raise for peak sensible.

• Balance returns salt air infiltrates windward cracks; pulls more air from interior halls/bedrooms at night.

• Add low-speed ceiling fans to destratify without kicking up CFM through the coil.

Visual airflow bias (ASCII)
[Windward wall] → less return | [Interior hall] → more return

Efficiency, refrigerant, and controls that actually matter

3C rewards variable-speed compressors, ECM blowers, and smart thermostats with humidity setpoints. Prioritize SEER2/HSPF2 at part-load, not just peak numbers. R-32 systems deliver strong efficiency with lower GWP, pair them with matched air handlers and coils to keep ratings intact.

Control tips

• Enable dehumidification with fan-off at call end (prevents re-evap).

• Use coastal setback: slightly higher cooling setpoint (e.g., 75–76°F) but strict 50–55% RH.

• Consider economizer lockouts; marine layer air may be cool but too wet for free cooling.

Installation details that prevent coastal call-backs

Even the best unit fails early if the install shortcuts salt control. Seal every penetration, slope pads for drainage, and maintain clear intake/exhaust paths away from surf-facing walls. Use SS or coated line-set hangers, UV-rated insulation, and sealed disconnects. On roofs, specify curbs with marine flashing and vibration isolation to limit galvanic wear.

Visual condenser siting (top view)
Prevailing wind → [10–15 ft open air] → [Condenser] → [Wall]
Avoid corners that trap salty eddies.

Checklist (clip & carry)

• SS hardware and weathertight electricals

• Trap and secure condensate in corrosion-resistant fittings

• Bonding/surge protection for coastal storms

• Hail/fin guards; removable for rinsing

Maintenance protocol and service intervals (coastal edition)

Write maintenance into the spec. Fresh-water rinse outdoor coils weekly in peak salt periods; monthly in off-season. Use non-acidic coil cleaners quarterly. Inspect cabinet coatings, touch up chips, and verify condensate treatment tabs are present. Indoor units need drain pan checks, float switch tests, and ECM blower dusting (salt + organic dust makes a sticky mix).

Suggested calendar

• Weekly: quick hose rinse of condenser

• Quarterly: coil clean, fastener check, electrical corrosion scan

• Biannual: full performance test, static pressure, and control calibration

• Annual: recoat exposed dings, replace UV-brittled insulation, review RH logs

Field note: Teach owners: hose only, no pressure washer, and rinse from the inside out if panels allow.

Need help scheduling? Help Center

Ductwork, ventilation, and IAQ for salty, humid air

Salt rides in on infiltration. Tighten ducts with mastic + mesh, not tape, and aim for ≤5% total leakage. Place returns away from windward leaks; consider central returns with jump ducts to bedrooms. For ventilation, ERVs often beat HRVs in 3C because they temper moisture during marine layer events. Use MERV 11–13 if the blower and duct static allow; otherwise, keep 8–11 but maintain filter cadence.

Condensate & materials

• PVC/CPVC traps with SS hangers; avoid cheap steel.

• Slope and secure condensate lines; salt-clogged traps overflow silently.

Budgeting, lifecycle, and how to present the spec

In 3C, total cost of ownership beats the first cost. The added price of marine coatings, SS hardware, and inverter control is usually recovered via fewer coil replacements, lower kWh in shoulder seasons, and fewer mold remediations. Quote both baseline and coastal-grade packages with a 10-year horizon. Include rinse bib install and service plan line items they’re small but high-impact.

Buying confidence

• Explore financing options to spread the upfront premium: HVAC Financing.

• Leverage protections: Lowest Price Guarantee .

• For hotels/multifamily, compare PTAC vs VTAC using this reference: PTAC Sizing Guide.

Ready to configure? Start at the Design Center.

Bonus: Mini-split head selection (visual quick-pick)

Room type      | Best head

-------------- | --------------------------

Bedrooms       | Wall mount or mini floor console (quiet + latent)

Living areas   | Ceiling cassette (even throw, low draft)

Kitchens       | Concealed duct (keeps coils away from grease)

ADUs/Offices   | Wall mount or PTAC/VTAC when ducts aren't practical

What to order (checklist you can copy into the PO)

• Coastal-grade R-32 heat pump or ductless mini-split (matched coil/air handler)

• Marine coating on coils + cabinet, SS fasteners kit

• ECM blower with dehumidify control and smart thermostat with RH setpoint

• Line sets (UV-rated insulation) + accessories (float switch, surge protector, rinse bib)

• ERV sized for occupancy, not just square footage

• Service plan with quarterly coil care
