Troubleshooting Guide — Common Furnace Issues and Fixes

0 comments

🏡 Introduction: Don’t Panic — Diagnose Like Savvy

When the furnace stops working, most homeowners think the worst — “Is it broken?!”
But Savvy knows better. Most heating issues aren’t disasters; they’re just small hiccups caused by filters, switches, or sensors doing their job.

“A good furnace has built-in safety features,” Savvy says. “When something’s off, it shuts itself down to protect you. My job is to figure out what it’s trying to tell me.”

This guide will walk you through the most common furnace issues — what causes them, quick fixes you can safely try, and when it’s time to call a pro.

Because once you understand how your furnace thinks, you’ll troubleshoot with confidence.

Goodman 96% AFUE 80,000 BTUs, Upflow or Horizontal Application Variable-Speed Two-Stage Natural Gas Furnace in a 17.5 in. Cabinet, Model GRVT960803BN

⚙️ 1. Furnace Basics: Understanding How It Works

Before jumping into fixes, let’s understand what’s going on behind those panels.

Your Goodman two-stage variable-speed furnace runs like a symphony — multiple parts working in harmony:

Thermostat: Tells the furnace when heat is needed.
Ignition system: Starts the gas burners safely.
Heat exchanger: Transfers warmth to the air.
Blower motor: Circulates air through your home.
Sensors and switches: Monitor pressure, flame, and safety.

When any of these steps fails or misreads, the system pauses — not breaks — until it’s safe again.

External reference: Energy.gov — How Furnaces Work.

“Understanding the sequence helps you pinpoint where things go wrong,” Savvy explains.

🚫 2. Furnace Won’t Turn On

Symptom: No response at all — no lights, no fan, no sound.

Possible causes:

Circuit breaker tripped.
Furnace power switch off.
Door safety switch open.
Thermostat not calling for heat.

Savvy’s Fix:

Check your home’s breaker box — reset the furnace circuit if tripped.
Locate the furnace’s power switch (looks like a light switch near the unit) and flip it on.
Open and firmly close the furnace access door — it must latch to engage the safety switch.
Verify thermostat mode is set to Heat and the set temperature is higher than the current room temperature.

If your furnace still won’t start after these checks, the control board or transformer may need professional testing.

“Nine out of ten times, it’s just a switch,” Savvy says with a grin. “Start simple before you assume the worst.”

❄️ 3. Furnace Blows Cold Air

Symptom: Furnace runs, but air from vents feels cool.

Common causes:

Dirty air filter restricting heat exchange.
Flame sensor dirty or faulty.
Igniter not firing burners.

Savvy’s Fix:

Replace the filter (a clogged one traps heat, triggering a blower safety cycle).
Turn off power, wait 10 minutes, then restart the furnace.
If ignition still fails, stop and call a pro — repeated ignition attempts can damage the igniter.

External reference: Goodman Learning Center: Furnace Blowing Cold Air.

“Cold air doesn’t always mean a broken furnace,” Savvy says. “Sometimes, it’s just your system protecting itself.”

🔁 4. Furnace Keeps Turning On and Off (Short Cycling)

Symptom: Furnace starts, runs briefly, then shuts off before reaching temperature.

Likely causes:

Clogged air filter.
Thermostat placed near a heat source.
Blocked exhaust vent or dirty flame sensor.

Savvy’s Steps:

Replace the air filter — short cycling is the first sign of restricted airflow.
Make sure all vents and returns are open.
Move objects (lamps, space heaters) away from the thermostat.
If it persists, schedule a cleaning for the flame sensor and pressure switch.

“Short cycling wastes energy and wears down parts faster,” Savvy explains. “It’s the HVAC version of stop-and-go traffic.”

🔇 5. Strange Noises or Vibrations

Symptom: Your normally quiet furnace starts rattling, whistling, or booming.

What it means:

Rattling: Loose panel or ductwork.
Whistling: Air restriction from filter or vent.
Booming: Delayed ignition — gas buildup igniting at once (dangerous).

Savvy’s Fix:

Tighten screws on access panels.
Replace dirty filters.
Vacuum vents and intakes.
If booming occurs, turn the system off and call a pro — this requires burner inspection.

External link: ACCA Noise Source Guide.

“A furnace shouldn’t make you jump,” Savvy says. “Goodman models are built for quiet — if you hear something new, pay attention.”

💨 6. Weak or Uneven Airflow

Symptom: Some rooms feel warm while others stay chilly.

Possible causes:

Leaky or blocked ductwork.
Dirty blower wheel.
Variable-speed blower not properly configured.

Savvy’s Fix:

Make sure all vents are open.
Check for visible duct kinks or loose connections.
Set thermostat fan mode to ON for 10 minutes — helps test airflow balance.

If rooms still feel uneven, ask your technician to inspect the blower speed settings and check for duct leaks.

External link: EPA Guide to Duct Sealing.

“Balanced airflow is the difference between comfort and frustration,” Savvy says.

💧 7. Water Around the Furnace

Symptom: Puddle or dripping near the base of the furnace.

Likely causes:

Condensate drain clog.
Disconnected drain tubing.
Faulty condensate pump.

Savvy’s Quick Test:

Turn off furnace power.
Locate clear PVC drain line and pour a cup of white vinegar through it to clear buildup.
Reconnect any loose tubing.
Restart and observe drainage.

If water persists, the secondary heat exchanger or drain trap may need inspection.

“A little leak can cause a big mess,” Savvy warns. “A quick vinegar flush keeps things clean.”

🔥 8. Furnace Turns On but No Flame Appears

Symptom: Blower runs, but burners don’t ignite.

Causes:

Flame sensor dirty or damaged.
Igniter cracked.
Gas supply interrupted.

Savvy’s Fix:

Don’t repeatedly reset the furnace — it can flood the chamber with gas.
Check gas valve to ensure it’s open.
Call a professional for sensor cleaning or igniter replacement.

“If you’re not comfortable working near gas or flame, stop. This is a pro job,” Savvy reminds.

External resource: Home Depot Furnace Ignition Troubleshooting.

⚠️ 9. Furnace Smells Strange

Furnace odors are your system’s language. Learn what they’re saying:

Smell	Meaning	Action
Dusty/Burning	Normal at first use	Wait 10–15 minutes
Rotten Eggs	Gas leak	Leave home & call utility
Mildew	Moisture in ducts or condensate line	Clean or call technician

“Never ignore a smell you can’t identify,” Savvy says. “Better safe than sorry.”

🔋 10. Furnace Won’t Stay Lit

Symptom: Burners ignite, but flame goes out after a few seconds.

Possible causes:

Dirty flame sensor.
Faulty pressure switch.
Draft issue or improper venting.

Savvy’s Fix:

Replace filter and restart furnace.
Ensure vent terminations outside aren’t blocked by snow or debris.
If flame keeps shutting off, call a certified pro to clean sensors and test airflow.

“Your furnace isn’t quitting on you — it’s just waiting for the all-clear to keep burning safely,” Savvy notes.

💡 11. Thermostat Works, But Furnace Doesn’t Respond

Symptom: Thermostat screen is active, but furnace stays silent.

Likely causes:

Blown fuse on control board.
Loose low-voltage wire.
Thermostat not set to correct stage (single vs. two-stage).

Savvy’s Fix:

Power-cycle the furnace by switching breaker off and on.
Check thermostat wiring if accessible.
Replace thermostat batteries.

If all else fails, the control board may need service.

External reference: Honeywell Thermostat Troubleshooting .

🧰 12. DIY Fixes vs. Pro Repairs

Savvy knows where to draw the line:

Issue	DIY	Call a Pro
Filter replacement	✅
Thermostat reset	✅
Cleaning vents	✅
Gas or ignition issues		❌
Repeated shutdowns		✅
Electrical faults		✅

“If it involves flame, wiring, or gas — that’s my cue to step back,” Savvy says. “Peace of mind is worth the service call.”

🧾 13. Savvy’s Emergency Furnace Checklist

When the heat’s out and you need warmth now:

Check thermostat batteries and settings.
Inspect circuit breakers.
Replace or clean air filter.
Make sure furnace door is closed securely.
Wait five minutes and restart.

If the furnace still won’t engage, call a professional and share these steps — you’ll help them diagnose faster.

Internal link: [Installation 101 — What to Expect When Setting Up a Two-Stage Gas Furnace]

🧠 14. Prevent Future Issues — The Maintenance Mindset

Most “breakdowns” aren’t breakdowns at all — they’re maintenance reminders.

Savvy’s prevention checklist:
✅ Change filters every 60–90 days.
✅ Schedule yearly tune-ups.
✅ Keep vents and drains clear.
✅ Listen for new sounds.
✅ Watch your energy bills for warning spikes.

External reference: EnergyStar Maintenance Tips.

“A few small habits keep my Goodman furnace happy,” she says. “It’s not luck — it’s consistency.”

🧩 15. Savvy’s Quick Diagnosis Chart

Symptom	Likely Cause	Fix
No heat	Thermostat or breaker	Reset / replace batteries
Cold air	Dirty filter or ignition issue	Replace filter, restart
On-off cycling	Blocked vents or flame sensor	Clean and test
Noisy operation	Loose parts / airflow restriction	Tighten panels, clean
Water leak	Condensate drain clog	Flush line with vinegar
