📘 Introduction: Why Troubleshooting First Saves You Money

As a homeowner, there’s nothing worse than realizing your HVAC system isn’t working — especially during a scorching July afternoon or a subzero January morning. A 3.5 ton AC with furnace is a robust system, but like any mechanical equipment, it can develop problems.

The good news?
Many common issues have simple fixes that you can do yourself, saving $100–$200 in unnecessary service calls. And even if you still need a pro, knowing what’s wrong means you can describe the problem more clearly, speeding up the repair.

This guide will help you:

Identify common problems for both AC and furnace.
Try safe, simple fixes yourself.
Know when it’s time to call in a certified technician.

❄ Common AC Problems & Fixes

1. AC Won’t Turn On

Possible Causes:

Tripped breaker.
Thermostat set to “heat” or “off.”
Disconnected or loose wiring.
Blown fuse in the disconnect box.

DIY Fixes:

Check your home’s electrical panel and reset any tripped breakers.
Confirm thermostat is set to “cool” and temperature is below room temp.
Inspect the outdoor disconnect for a tripped fuse (turn off power first).

2. Weak Cooling

Possible Causes:

Dirty air filter.
Blocked return or supply vents.
Dirty evaporator or condenser coil.
Low refrigerant charge.

DIY Fixes:

Replace or clean filter.
Ensure vents aren’t blocked by furniture or curtains.
Clear debris from outdoor condenser and rinse coils gently.
If you suspect low refrigerant, call a pro — refrigerant handling requires EPA certification.

3. Frozen Coil

Possible Causes:

Restricted airflow from dirty filter or blocked vents.
Low refrigerant.
Blower fan malfunction.

DIY Fixes:

Replace filter and open all vents.
Turn system off to let ice thaw completely before restarting.
If freezing returns, have refrigerant level checked.

4. Short Cycling

Possible Causes:

Oversized AC unit.
Dirty condenser coil.
Faulty thermostat placement (near heat source or in direct sunlight).

DIY Fixes:

Clean condenser coil.
Relocate thermostat away from heat sources.

📎 Reference: Energy.gov – AC Troubleshooting

🔥 Common Furnace Problems & Fixes

1. Furnace Won’t Ignite

Possible Causes:

Thermostat not calling for heat.
Gas valve closed.
Faulty igniter or pilot light.

DIY Fixes:

Set thermostat to “heat” and raise temp.
Ensure gas valve is open.
For pilot systems, relight according to manufacturer instructions.

2. Blower Runs Constantly

Possible Causes:

Thermostat fan setting on “ON” instead of “AUTO.”
Stuck fan relay.

DIY Fixes:

Switch fan setting to “AUTO.”
If fan still runs, relay may need replacement (pro job).

3. Uneven Heating

Possible Causes:

Leaky ducts.
Closed or blocked vents.
Improper blower speed.

DIY Fixes:

Inspect ducts for visible gaps and seal with UL-181 mastic.
Open all vents for balanced airflow.

4. Loud Noises

Possible Causes:

Loose panels.
Worn blower motor bearings.
Expansion and contraction in ductwork.

DIY Fixes:

Tighten screws on access panels.
Call a pro for bearing replacement.

📎 Reference: Energy Star – Furnace Maintenance

🛠 Tools Every Homeowner Should Have for Basic HVAC Troubleshooting

Digital Thermometer: For checking supply/return temperature split.
Multimeter: For basic voltage and continuity tests.
Screwdriver Set: For removing access panels.
Flashlight/Headlamp: For inspecting dark areas.
Filter Gauge: To check airflow restriction.

🚫 When to Call a Professional Immediately

Gas Smell: Possible leak — turn off system, leave home, call gas company.
Burning or Electrical Smell: Shut off power and call an HVAC technician.
Frequent Breaker Trips: Could indicate electrical fault.
Refrigerant Issues: Legally requires EPA Section 608 certified tech.

📎 Reference: EPA Section 608 Certification

📊 Troubleshooting Quick-Reference Chart

Symptom	Likely Cause	DIY Fix	Pro Needed?
AC won’t turn on	Breaker, thermostat, disconnect	Reset breaker, check settings	If still no power
Weak cooling	Dirty filter, blocked vents, dirty coil	Replace filter, clean vents/coil	Low refrigerant
Frozen coil	Airflow restriction	Replace filter, open vents	Refrigerant leak
Furnace won’t ignite	Gas valve closed, bad igniter	Open valve, relight pilot	Igniter replacement
Uneven heating	Duct leaks, closed vents	Seal ducts, open vents	Duct redesign
Loud noises	Loose panels	Tighten screws	Motor repair

✅ Preventing Future Issues

Change Filters Regularly (every 1–3 months).
Keep Outdoor Units Clear — at least 2–3 feet of space around condenser.
Schedule Seasonal Tune-Ups — spring for AC, fall for furnace.
Seal Duct Leaks — reduces strain on blower.
Install Surge Protection — protects electronics in furnace/AC.

📎 Reference: ACCA Maintenance Guidelines

📌 Mark’s Pro Tips

Always turn off power at the breaker before opening panels.
Keep a troubleshooting log — date, symptoms, and actions taken.
Take photos of wiring before disconnecting anything.
Don’t ignore small noises or odd smells — early fixes are cheaper.

📎 Verified External References

✅ Conclusion

A 3.5 ton AC with furnace is a reliable year-round comfort system, but like any mechanical equipment, it can hit snags.
With this troubleshooting guide, you can:
