Step-by-Step Installation Guide for Your 10k–12k Through-the-Wall AC (DIY-Friendly!)
If you’ve ever looked at a through-the-wall AC and thought, “That looks complicated,” I promise you — it’s way more doable than you think. With the right tools, proper prep, and a little Savvy guidance, installing a 10,000–12,000 BTU through-the-wall air conditioner becomes a weekend project that delivers years of powerful, quiet, reliable cooling.
The big secret?
Success isn’t about being “handy.” It’s about following the right sequence, making smart decisions before cutting anything, and doing the small details correctly — because those are what keep your AC efficient and your wall safe from leaks, mold, or structural headaches later.
Let’s get into this the Savvy way — clear steps, zero stress, and tons of pro-level insight you won’t get from the manufacturer's manual.
1. Tools & Materials Checklist (Savvy’s Verified Essentials)
Before any cutting, drilling, measuring, or sleeve sliding happens, you need a clean, complete tool layout. Missing just one item causes… delays. And sweaty frustration. Ask me how I know.
Here’s your full list.
Power Tools
-
Reciprocating saw (with wood and metal blades)
-
Drill + driver
-
Hole saw (optional for perfect pilot holes)
-
Jigsaw (optional for vinyl siding)
-
Stud finder with AC wire detection
-
Orbital sander (optional for smoothing cut edges)
-
Level — 24" or longer
Hand Tools
-
Measuring tape (at least 25 ft)
-
Hammer
-
Pry bar
-
Carpenter’s square
-
Utility knife
-
Pencil + marker
-
Screwdrivers
-
Staple gun (for insulation barrier repair)
Materials
-
AC-compatible wall sleeve (never skip this — more on that below)
-
Pressure-treated 2×4 lumber for framing
-
Weatherproof exterior silicone caulk
-
Flashing tape (window/door grade)
-
Rigid flashing or drip cap
-
Fiberglass insulation
-
Deck screws (1 ½"–3")
-
Shims
-
Trim or casing for interior finish
-
Drop cloths
-
Painter’s tape
Safety Gear
-
Eye protection
-
Gloves
-
Dust mask or respirator
-
Closed-toe shoes
-
Hearing protection
Savvy Safety Note:
Do NOT attempt any cuts without eye protection. Even small chips of siding or brick can fly farther and faster than you expect.
2. Picking the Perfect Location (90% of Success Happens Here)
Location determines:
-
cooling efficiency
-
noise level
-
drainage performance
-
structural safety
-
how hard the install becomes
-
whether the AC lasts 5 years or 15
So before we lift a saw, we scout and plan.
What You’re Looking For
✔ A section of wall with no plumbing, electrical, or hidden ductwork
✔ On an exterior wall (interior walls won’t work — ever)
✔ About shoulder height inside the room
✔ Unblocked airflow outside — no bushes, fences, or decks
✔ Near your electrical outlet
✔ Not under a constant roof drip line
Avoid These Mistakes
❌ placing the AC too high (warm air stays trapped)
❌ installing on a west-facing wall in hot climates (overheats the AC)
❌ placing the AC behind furniture
❌ choosing a wall with brick veneer if you have no masonry tools
❌ blocking outdoor exhaust airflow
How to Check the Wall Safely
-
Use your wire-detecting stud finder.
-
Mark all studs.
-
Use a drill and a tiny pilot hole to check insulation depth.
-
Look in your attic or basement to see if wires run through that stud bay.
-
If the home is older than 1978, assume plaster + lath, not drywall.
Savvy Safety Note:
Never rely solely on a stud finder for wiring detection. Always verify by opening a small inspection hole.
3. Cutting the Opening (Relax — This Is the Easy Part When Done Right)
People are scared of cutting the wall, but truthfully?
The prep and measuring matter more than the cutting itself.
Step 1 — Mark Your Opening Accurately
Your wall sleeve will list exact rough opening dimensions.
Use a tape measure + level to mark:
-
Top line
-
Bottom line
-
Left stud line
-
Right stud line
Double-check everything before cutting.
Savvy Says:
Measure three times. Cut once. And then smile knowing you avoided a headache.
Step 2 — Cut a Small Inspection Window
Cut a 4" × 4" access hole at the center of your outline.
Why?
-
Find wiring
-
Identify insulation
-
Check for plumbing
-
Verify stud positions
-
Feel wall thickness
This single step prevents all major DIY disasters.
Step 3 — Cut Away the Interior Drywall
Use a reciprocating saw or drywall saw to cleanly cut along your outline.
Remove:
-
drywall
-
insulation
-
old vapor barrier (you’ll repair it later)
Set all materials aside neatly.
Step 4 — Deal With Studs (The Most Technical Step)
Most through-the-wall sleeves require a rough opening wider than 14.5", meaning you’ll cut at least one stud.
Cutting a stud is fine — handling it correctly is what matters.
What You’ll Do
-
Cut out the stud section inside the opening.
-
Build a header (a mini window-style load distribution beam).
-
Install king and jack studs to support the header.
-
Add a sill plate to support the bottom of the sleeve.
Framing this opening is almost identical to framing a new window.
Savvy Safety Note:
If the wall is load-bearing, do NOT cut a stud unless you understand structural reframing — or bring in a pro.
Step 5 — Cut the Exterior Wall
This is where the real commitment happens.
You’ll:
-
Drill pilot holes at the corners from inside → outside.
-
Go outside and connect the pilot holes with chalk.
-
Use your reciprocating saw to cut the siding or sheathing.
Material-Specific Advice
Vinyl: Easy — follow the chalk line slowly.
Wood: Moderate — watch for nails.
Stucco: Dust storm. Wear a respirator.
Brick: Use a masonry blade. Slow and steady.
Stone: Bring a pro. Seriously.
4. Installing the Wall Sleeve (The Step Most Manuals Explain Poorly)
This step determines:
-
how quiet your AC runs
-
whether water drains outside
-
if mold will ever form in your wall
-
how long the unit lasts
So let’s do this right — Savvy style.
Step 1 — Slide the Sleeve Into Place
It should be snug but not forced.
If it’s:
-
too tight → plane the sill or frame
-
too loose → shim carefully
The sleeve should not move when pushed.
Step 2 — Create the Mandatory Drainage Slope
Tilt the sleeve ¼ inch downward toward the outside.
This is non-negotiable.
Why?
Condensation water must drain outward — not back into your wall framing.
Energy.gov confirms improper draining of ACs is a major cause of home moisture problems.
Step 3 — Fasten the Sleeve Securely
Use:
-
sleeve brackets
-
manufacturer screw points
-
structural screws
Never drill into random sleeve locations — they are engineered for airflow.
Step 4 — Weatherproof Like a Pro
Exterior:
-
Flashing tape layered shingle-style
-
Drip cap above the sleeve
-
Silicone around all seams
-
Check for backflow gaps
EPA documentation shows that unsealed wall penetrations cause moisture intrusion and mold risk.
Interior:
-
Add fiberglass insulation (never expanding foam — it warps sleeves)
-
Seal edges with paintable caulk
-
Reinstall or add trim
5. Installing the AC Unit (Deep Breath — This Part Is Fun)
Once your sleeve is installed like a champ:
-
Remove packing foam
-
Slide the AC into the sleeve rails
-
Push until the locking tabs click
-
Install any side sealing pads
-
Plug into the correct outlet
-
Turn on cooling mode
-
Check for rattles or movement
If you hear vibration, the sleeve may not be level or needs better shimming.
Energy Star notes that proper alignment reduces excess noise and improves efficiency.
6. Drainage + Sealing Tips (Savvy’s Performance Boosters)
Your AC’s long-term success depends on correct drainage and air sealing more than any other factor.
Drainage Musts
-
Rear of sleeve LOWER than the front
-
Exterior clearance (8–12 inches open space)
-
Drain hole unobstructed
-
No mulch or soil built up against the unit
-
Splashback issues = incorrect slope
Air Sealing Musts
Interior:
-
Fiberglass insulation only
-
Finish with trim
-
Seal hairline gaps with caulk
Exterior:
-
Use UV-safe silicone
-
Correctly taped flashing
-
No visible daylight from inside
EPA guidance highlights how even small air leaks reduce AC efficiency dramatically.
7. Savvy Safety Notes (All in One Place)
Safety Note #1:
Check for live wires with a proper detector.
Safety Note #2:
Never cut a stud in a load-bearing wall unless reframing is done correctly.
Safety Note #3:
Wear a respirator when cutting stucco, stone, or insulation.
Safety Note #4:
Always maintain sleeve slope — improper drainage = wall rot.
Safety Note #5:
Use the correct voltage outlet (115V vs 230V).
Wrong outlet = tripped breakers or fire hazards.
8. Final Savvy Summary: Yes — You Can DIY This Like a Pro
Installing a 10k–12k BTU through-the-wall AC isn’t just doable — it’s one of the most satisfying DIY upgrades you can make. You end up with:
-
quieter operation
-
better energy efficiency
-
a clean, permanent installation
-
a reclaimed window
-
improved home comfort
-
a modern look
And best of all?
You get the “I built that” pride every time summer heat rolls in.
In the next blog, you will uncover "How Efficient Are 10k–12k Through-the-Wall AC Units?".
