Introduction from Mike
Hey there, neighbor. Mike Sanders here—just your average handy guy who’s been elbows deep in HVAC systems for longer than I care to admit (okay, 20+ years). If you’ve got the Goodman GLXS4BA3610 R-32 condenser, matched with the CAPTA3626C3 vertical coil and GR9T961005CN gas furnace, you’ve made a solid choice. But like anything mechanical, even the best gear can run into hiccups.
Let me walk you through the usual suspects when this 3-ton powerhouse acts up—and how to handle them without bustin’ your knuckles (or your wallet).
1. System Not Cooling Properly 😰
Problem:
You set the thermostat to a chill 72°F and… nothing. Warm air, weak airflow, or a unit that won’t kick on.
Fixes to Try:
-
Check the thermostat settings – Sounds simple, but you'd be surprised.
-
Make sure the disconnect switch outside by the condenser hasn’t been tripped.
-
Inspect your air filter – a clogged one can choke airflow like a scarf in summer.
-
Look for a frozen evaporator coil – if you see ice, turn the system off and let it thaw.
👉 If the problem sticks around, it might be low refrigerant—which leads us to...
External Reference:
HVAC.com - Why Isn’t My AC Cooling?
2. R-32 Refrigerant Leaks 🔧
Problem:
R-32 is efficient and eco-friendlier than R-410A, but it’s still a pressurized refrigerant—and leaks can mean your system struggles or shuts down entirely.
Fixes to Try:
-
Look for oily residue around line set connections or the indoor coil.
-
Use a leak detector or bubble solution to check connections.
-
Never top off the charge without sealing the leak—it’s throwing good refrigerant after bad.
Important Safety Tip:
R-32 is mildly flammable (A2L class), so ventilate well and follow all safety standards when handling it. Wear gloves, goggles, and don’t smoke near the system. Seriously.
External Reference:
ASHRAE Guide to A2L Refrigerants
3. Furnace Keeps Cycling On and Off 🔁
Problem:
The gas furnace fires up and then shuts down within a few seconds or minutes. This "short cycling" can wear out your unit and jack up your gas bill.
Fixes to Try:
-
Check the flame sensor – give it a gentle clean with steel wool.
-
Inspect for vent blockages – wasp nests, leaves, and bird nests are all common culprits.
-
Ensure proper gas pressure and that the drain lines are clear.
Sometimes, this is a sign the furnace is oversized for the home or not ventilating correctly.
External Reference:
Indoor Temp - Understanding Short Cycling
4. Loud or Unusual Noises from the Condenser Unit 🔊
Problem:
That humming or buzzing isn’t just annoying—it’s usually a red flag. Screeching, rattling, or grinding noises should never be ignored.
Fixes to Try:
-
Buzzing? Check for a failing contactor or capacitor.
-
Screeching? That could be a bad fan motor bearing.
-
Rattling? Loose screws, a bad compressor mount, or debris inside the housing.
DIY Tip:
Kill power at the disconnect before opening anything. Safety first, always.
External Reference:
Bob Vila - Common AC Noises and Their Fixes
5. Error Codes on the Control Board ⚠️
Problem:
If your system is flashing LED codes on the furnace control board, it’s trying to tell you something—listen!
Fixes to Try:
-
Grab the furnace manual and look up the flashing sequence.
-
Common codes include:
-
Flashing 3 times = pressure switch problem
-
Flashing 4 times = limit switch open
-
Flashing 7 times = flame sensor error
-
Take a picture of the code, reset the system, and monitor it. If it reappears, time to dig deeper or call a tech.
External Reference:
Goodman Furnace Error Code Guide
6. Furnace Won’t Ignite in Winter ❄️
Problem:
When the furnace won’t start but the thermostat is calling for heat, you could be dealing with a failed ignitor, bad control board, or blocked flue.
Fixes to Try:
-
Look for the orange glow of the ignitor. No glow? Test it with a multimeter.
-
Blow out the pressure switch hose and drain trap.
-
Check for bird nests or obstructions in the exhaust pipe.
External Reference:
Family Handyman - Gas Furnace Troubleshooting
Mike’s Final Tip 🧰
You made a solid choice with this Goodman system. It’s efficient, uses the future-friendly R-32, and when paired properly, gives your home year-round comfort without gobbling energy.
That said, no system is bulletproof. Keep an eye on it, listen for changes, and stay ahead of maintenance. Even if you're not a licensed tech, a little know-how and some homeowner vigilance go a long way.
If you're ready to upgrade, need a matching part, or want to check out the full specs, here’s where to find the full system:
👉 Goodman 3 Ton 15.2 SEER2 System – GLXS4BA3610, CAPTA3626C3, GR9T961005CN
Need more maintenance tips for this combo? Visit: Maintenance Checklist for the Goodman GLXS4BA3610 / CAPTA3626C3 / GR9T961005CN System.
Stick around for more of my no-fluff homeowner guides. I’ve got your back. 💪
- Mike, your cool HVAC Neighbor
