How to Safely Install and Start Up Your Goodman 96% AFUE Gas Furnace (GR9S960803BN)

🔧 Introduction: Mike’s Furnace Safety Talk

Hey folks, Mike here! Installing a gas furnace might sound intimidating, but with some prep, attention to detail, and a healthy respect for safety, it’s completely doable. Today we’re walking through the Goodman GR9S960803BN 96% AFUE furnace, focusing on installation, proper venting, gas hookups, and first-time startup.

Remember: gas and electricity are no joke—if something doesn’t feel right, call a licensed professional. Safety first! 🔥🛠️



🏗️ Part 1: Preparing for Installation

Step 1: Choose the Correct Location

• Install the furnace on a level, stable surface.

• Ensure adequate clearance around the unit for airflow and maintenance access.

• Avoid placing the furnace in areas prone to moisture or flooding.

For detailed safety and placement guidelines, check out InterNACHI’s furnace safety guide.

Step 2: Inspect the Furnace

• Remove the furnace from its packaging carefully.

• Inspect for damage to panels, burners, or the heat exchanger.

• Check that all accessories (venting kit, screws, manuals) are included.

Step 3: Gather Tools & Safety Gear

• Adjustable wrenches and screwdrivers

• Level and drill

• Pipe sealant rated for gas lines

• Multimeter for electrical checks

• Safety gloves, goggles, and mask



🛠️ Part 2: Gas Line Connection

Step 1: Turn Off the Main Gas Supply

• Safety first: ensure the main gas valve is completely off.

Step 2: Connect the Gas Line

• Use black iron or approved CSST pipe per local codes.

• Apply pipe sealant on threaded connections.

• Tighten securely without over-torquing.

Step 3: Test for Leaks

• Open the main gas supply slowly.

• Use a gas leak detector or soap solution on all joints to check for leaks.

• Never skip this step! Even a small leak can be dangerous.

For additional guidance, see this natural gas furnace installation checklist.



🌬️ Part 3: Venting Installation

Step 1: Install Vent Piping

• The GR9S960803BN uses direct venting for safe combustion.

• Follow manufacturer specs for length, elbows, and termination points.

• Ensure vent pipes slope slightly upward to avoid condensation issues.

Step 2: Check for Proper Clearances

• Maintain distance from combustible materials per local codes.

• Inspect vent terminations to ensure exhaust gases are safely released outdoors.

For venting best practices, Energy.gov’s furnace efficiency guide is a great reference.



🔌 Part 4: Electrical Connections

Step 1: Power Supply

• Ensure the furnace is disconnected from the power source before wiring.

• Connect according to the manufacturer’s diagram, typically 120V single-phase.

Step 2: Thermostat Wiring

• Connect thermostat wires to the appropriate terminals.

• Double-check polarity and labels to avoid reversing heating/cooling signals.

Step 3: Safety Switches

• Verify all limit and pressure switches are properly connected.

• These are critical for preventing overheating and unsafe operation.



⚡ Part 5: Startup & Safety Checks

Step 1: First Ignition

• Turn on the power and gas supply.

• Set the thermostat to call for heat.

• Listen for smooth ignition and burner operation.

Step 2: Monitor Operation

• Observe burners for steady flame and even heat.

• Check for unusual sounds or vibration.

• Ensure blower starts and airflow is consistent.

Step 3: Inspect Carbon Monoxide Safety

• Install a CO detector near the furnace.

• Check for any signs of vent blockage or incomplete combustion.

For more CO safety tips, refer to EPA’s carbon monoxide resources.



🧰 Mike’s Pro Tips

• Label Everything: Wire labeling during installation saves headaches later.

• Double-Check Clearances: Venting and clearance specs are critical for efficiency and safety.

• Routine Maintenance: Schedule annual inspection and cleaning to maintain 96% AFUE efficiency.

• OEM Parts Only: Stick with Goodman parts for replacements to avoid warranty issues.



🏁 Conclusion: Mike’s Final Word

Installing the Goodman GR9S960803BN 96% AFUE gas furnace doesn’t have to be stressful. Take your time, follow manufacturer instructions, and prioritize safety at every step.

If you want to see the full furnace bundle including the condenser and coil we’ve been working with, check out the Goodman 2-Ton 14 SEER2 Northeast System.

With careful installation, proper venting, and thorough startup checks, your furnace will deliver reliable, safe, and efficient heating all winter long.

Need more advanced troubleshooting tips for this bundle? Visit my guide: Troubleshooting Made Easy.

Stay safe, stay warm, and keep those tools handy! 🔧🔥

- Mike, your cool HVAC neighbor!
